Specifications
1.test 12 cylinders pump max.2.CE certificate
3.rotative and line pumps.
4.digital controll
12PSB-C Diesel fuel injection pump test bench (CE ceritficate)
FUNCTIONS
1 12-cylinder diesel fuel injection pump can be tested
2 Measure each cylinder delivery at any speed.
3 Check each cylinder injection timing with static.
4 Checking the sealing injection pump body.
5 Check the mechanical governor.
6 Check the pneumatic governor.
7 Check the vacuum capacity of governor.
8 Check the pressure compensators (LDA).
9 Measure the internal pressure of distributor pump body.
10 Test the electromagnetic valve of distributor pump.
11 Check the transfer pump.
Features:
1, It adopts advanced frequency changing technology,stable performance,adjust the pump speed in a large range,low noise,save power energy.
2. Digital shows the pump speed,times and temperature..
3. With the 12V,24V DC electric source, for VE pump using DC power.
4. RPM setting, can set the pump speed freely.
5. With the high-pressure and low-pressure fuel system, can provide enough fuel and stable fuel supply,but also can test the pump sealing.
6. It has the positive and negative air pump, can provide the stable and adjusting air source.
7. VE pump chamber gauge and fuel return measuring.
Technical Parameters:
Output power |
7.5kw,11kw.15kw.8.5kw,22kw |
Power supply |
3-phase 380V/50HZ,3 phase-220V/50HZ |
Interaxe height |
125mm |
graduates |
45CC,150CC |
Tank volume |
60L |
DC supply |
12/24V |
Feeding fuel pressure |
Low 0--0.4Mpa, High 0--4Mpa |
Range of speed |
+/-4000RPM |
Filter accuracy |
5u |
Air pressure |
-50+300Kpa |
Size: |
2.3*1*1.9m |
Weight |
1000kg |
Display |
15” or 17” |
Package |
Wooden case |
Hot Questions:
1.Does your company a distributor or a manufacturer?
Our company is specialized in the producing of the diesel fuel injection test bench by ourselves for more than 10 years, we have our factory and so can provide you the best price.
2.Is the operation easy?How about the instructions?
Dear customer,we design the machine for the beautiful style and easy operation. We provide the operation instructions with the machine even in your language.And also can provide the operation vedio.
3.Payment method and the delivery time.
We accept bank transfer,Western Union or Paypal. Accept L/C,TT.
The machine will be produced as soon as possible when receive the payment,often within 8 days.
waiting for your inquiry!!!
