Specifications
CRI-1000Rich accessories, ready to test Bosch, Denso and Delphi injectors
CRI-1000
The repair tester for Common Rail Injector CRI-1000 simulates the outputs of an Engine Control Unit (ECU) to provide user adjustable fuel injection control signals for driving the solenoid of a common rail injector.
The CR injector being tested is fed by a high pressure fuel source, which may be a mechanical manual pump or an electrical motor driven pump or a pneumatic driven pressure booster. Such a test device will fulfill the tasks of checking nozzle spray pattern, injector back leakage and solenoid condition.
Design Features
Modulated driving signal to ensure the safety of the injector solenoid
Adjustable frequency and pulse width for the injector driving signal
Short circuit protection for solenoid driving signals
Rich accessories, ready to test Bosch, Denso and Delphi injectors
Send Inquiry to This Supplier
