Best selling small scale peanut oil processing plant
We are one of TOP 10 Cereals & Oil Machinery Brand Manufacturers in China. This production line includes seed oil pretreatment and pre-pressing machine, oil cake extraction machine and seed oil refining machine.
Best selling small scale peanut oil processing plant
1. oil seed pretreatment and prepress plant
seeds→Magnitic seperating( Metal impurities)→cleaning →husking→ flaking roll→Cooking →pressing workshop
Main Equipments of oil extraction machine
1. Raw material : peanut,soybean,rapeseed,sesame seed , sunflowerseeds,linseed, pumpkinseeds,cottonseed etc.
2. Magnetic box: Clearing the iron impurity which might be in the seed.The iron impurity will be harmful to the following machines, so we need take the iron impurities out.
3. Cleaning: This parts have different size cleaning sieves to clean the different impurities. After
going through this part, most of the impurities are moved from seed .
4. Husking:this can help improve the oil yield from seed,and reduce wear to the machine .
5. Flaking: making use of the mechanical action to flake the seed into flakiness.After flaking, the
materials is becoming thiner thank,it is good for absorb moisture and heat in cooking process
and it is much easier for getting seed oil in machines for turmeric oil extraction plant process.
6. Cooker: This machine can adjust the water content of the seed. It’s also good for oil press and oil extraction section
2. oil extraction machine
Main Features of oil extraction machine
Moisture of extraction material |
5-8% |
temperature of extraction material |
50-55°C |
oil content of extraction material |
50-55°C |
oil content of extraction material |
14-18% |
thickness of extraction cake |
less than 13mm |
powder porosity of extraction material |
less than 15% (30 mesh) |
steam |
more than 0.6Mpa |
solvent |
national standard No. 6 solvent oil |
electric powe |
50HZ 3*380V±10% |
Electric lighting |
50HZ 220V ±10% |
tempreture of supplement water |
less than 25°C |
Hardness |
less than 10 |
volume of supplement water |
1-2m/t raw material |
temperature of recycle water |
less than 32°C |
3. oil refining process
Crude oil → degumming and deacidification→ decolorization →deodorization → refined oil.
Main Process of turmeric oil extraction plant
1. Degumming and deacidification: The gumming is moved by phosphoric acid and hot water.
2. Decolorization: This step is used to adjust the color of the oil.
3. Deodorization: The function of this step is to move the special smell in the oil. This is an important standard for refined oil.
Country |
Project Name |
Raw material |
Year |
Bangladesh |
30T/D rice bran expanding and extraction , 5T/D rice bran oil refining project |
Rice bran |
2013 |
Malaysia |
100T/D palm fruit oil refinery project |
Palm fruit |
2012 |
Sudan |
The whole production line for 30T/D peanuts oil expeller press |
Peanuts |
2011 |
Bolivia |
60T/D soybean oil refinery project |
Soybean |
2011 |
Indonesia |
30T/D copra oil extraction , and 20T/D copra oil refinery |
Copra |
2012 |
Kazakhstan |
3T/D cotten seeds oil refinery project |
Cotten seeds |
2012 |
Main Projects Scope:
30-5000T/D oilseeds pretreatment project
30-5000T/D oilseeds extraction project
5-1000T/D crude oil refining project
5-1000T/D crude oil fractionation project
Oil interesterification project
Oilseeds protein, phospholipid project
Natural pigment extraction project
Grain deep processing project
Typical Project:
30-1000T/D rice bran pretreatment, expanding, extraction project
30-600T/D rice bran oil refining project
150-1000T/D cottonseed dephenolizing protein
10-1000T/D palm fruit oil pressing project
10-500T/D Non acid method biodiesel production project
10-2000T/D corn deep processing project
Newest Technology:
Energy saving oil vacuum deodorization technology
Concentrated protein extraction technology
Mixed oil extraction technology
Mixed oil refining technology
Molecular distillation technology
Broken rice desaccharification technology
Continuous lignite extraction technology
Warmly Welcome your inquiry for more information !!
