ZT30B-32 CNC turret punching machine,cnc punching machines price
| Model | Description | Show |
| HYZT30BY | Close type hydraulic CNC turret punching machine | |
| HCKB | Close type hydraulic CNC turret punching machine | |
| HYZT25AY | Open type hydraulic CNC turret punching machine | |
| HCK | CNC Thick Plate Hydraulic Punching machine | |
Parameter |
Unit |
HYZT30BY |
HYZT25AY |
HCK |
HCKB |
Nominal Pressure |
KN |
300/500 |
250 |
400-1600 |
400-2000 |
Once punched maximum diameter |
mm |
Φ88.9 |
Φ88.9 |
As requirement |
Φ88.9 |
Maximum Workpiece Size |
mm |
1500*2500 |
1500*2500 |
2500*800 |
2000*3000 |
Max. Workpiece Weight |
kg |
100 |
100 |
As requirement |
As requirement |
Punching Accuracy |
mm |
±0.1 |
±0.1 |
±0.15 |
±0.15 |
Times of highest Stroke of Punch |
h.p.M |
550 |
220 |
50-80 |
50-80 |
Maximum plate feeding speed |
m/min |
60 |
60 |
40 |
40 |
Dimension(L*W*H) |
mm |
5500x4200x2300 |
5300x3500x2400 |
As requirement |
5500x4200x2300 |
Turret mode bits |
set |
16/24/32 |
16/24/32 |
6-9 |
6-9 |
Clamps structure |
|
Full floating type |
|||
Power |
|
Hydraulic |
|||
CNC system |
|
NCT-04 or SIMENS |
|||
Qingdao HaoYiYuan machinery co., LTD., located in the beautiful west coast of Qingdao, which is near by the Qingdao qianwan port, Qingdao international airport, the traffic is very convenient.
Our company mainly produces are CNC punching machine, CNC turret punch, nc feeder, nc plate CNC punch press and non-standard punching production line equipment, etc.
HaoYiYuan strives for perfection, strive for perfection, and always insist the integrity rigorous and pragmatic attitude on giving the first-class products, first-class service to our customer.
