ZT30B-32 CNC turret punching machine,metal sheet press
| Model | Description | Show |
| HYZT30BY-24 | Close type hydraulic CNC turret punching machine | |
Parameter |
Unit |
HYZT30BY-24 |
Normal Force |
KN |
300 |
Once punched maximum diameter |
mm |
Φ88.9 |
Maximum Workpiece Size |
mm |
1250*2500 |
Max. Workpiece Weight |
kg |
100 |
Punching Accuracy |
mm |
±0.1 |
Times of highest Stroke of Punch |
h.p.M |
550 |
Maximum plate feeding speed |
m/min |
60 |
Dimension(L*W*H) |
mm |
5500x4200x2100 |
Turret mode bits |
set |
24 |
Clamps structure |
|
Full floating type |
Power |
|
Hydraulic |
CNC system |
|
NCT-04 or SIMENS |
Qingdao HaoYiYuan machinery co., LTD., located in the beautiful west coast of Qingdao, which is near by the Qingdao qianwan port, Qingdao international airport, the traffic is very convenient.
Our company mainly produces are CNC punching machine, CNC turret punch, nc feeder, nc plate CNC punch press and non-standard punching production line equipment, etc.
HaoYiYuan strives for perfection, strive for perfection, and always insist the integrity rigorous and pragmatic attitude on giving the first-class products, first-class service to our customer.
1. Installation
There are one to three engineers will be send to your company to install and test the machine;(costomer need to pay for the engineers' business trip expense, and prepare the assembly tools)
2. Payment
30% down payment and the balance should be paid before shipment.
3. OEM or ODM
We can do that for you.
4. Supply full english documents
including foundation drawings, manual book, electric wiring diagram, electric manual book and maintenance book,etc.
