Closed CNC Turret Punching Machine/CNC punch press/High quality Mechanical CNC Punching machine
- 1000 Set / Sets per Month
- Qingdao or other chinese port
- T/T
- Professional High Precision Wide Application J23-25 cnc turret punching machines
- High Precision Wide Application J23-25 c frame punch press
- Professional High Precision Wide Application J23-25 hydraulics
- High Precision Wide Application J23-25 c frame fixed table punching machine
- Factory Sale High Precision Wide Application J23-25 construction material making machine
- High Precision Wide Application J23-25 scrap metal cutting machine for punching machine
Product Details
Condition: | New | CNC or Not: | CNC | Power Source: | Mechanical |
Place of Origin: | Shandong, China | Brand Name: | HaoYiyuan | Model Number: | HYZT30B |
Voltage: | 380V or Customized | Power(W): | 11Kw | Weight: | Accoring to the machine model |
Dimension(L*W*H): | 5500*4200*2300mm | Certification: | ISO | Warranty: | One Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CNC Turret Punching Machine/CNC punch press/Automatic Mechanical Punching machine
Dear Friends
Thankful your attention on our website first, our company has nearly 10 years' experience on CNC punching machine. We can assure you that we will meet your all requirements with positive and enthusiastic attitude.
If you want to know more details about our product or our company, please connect with me anytime or visit our Website, which on the first picture.
Yours
George
Product Description
Closed type Mechanical CNC Turret Punching Machine HYZT30B can been widely used in voltage switchgear, control panel, air conditioner panel,box,cabinet, shell, metal furniture, kitchen utensils and appliances, advertising and other panel punching processing companies. And also the accessories can be designed according to your requirements.
Specification
Name | Unit | Specific parameters (HYZT30B) | |||
Nominal force | KN | 300 | 500 | ||
Workpiece size | mm | 1250*2500 | 1500*2500 | 1250*2500 | 1500*2500 |
Max plate feeding speed | m/min | 80 | 80 | ||
Max thickness of sheet | mm | 3.0 | 6.0 | ||
Number of stations | Pcs | 16/20/24/32 | 16/24/32 | ||
Punching Accuracy | Mm | ±0.1 | |||
Punching frequency | Hpm | 260 | 180 | ||
Air pressure | Mpa | 0.55 |
Picture show
The apperance of the Mechanical CNC Punching Machine HYZT30B
The detail of the CNC Punch Press HYZT30B
The detail of the contol system box
A part of our manufacturing plant
Company Information
Qingdao HaoYiYuan machinery co., LTD., located in the beautiful west coast of Qingdao, which is near by the Qingdao qianwan port, Qingdao international airport, the traffic is very convenient.
Our company mainly produces are CNC punching machine, CNC turret punch, nc feeder, nc plate CNC punch press and non-standard punching production line equipment, etc.
HaoYiYuan strives for perfection, strive for perfection, and always insist the integrity rigorous and pragmatic attitude on giving the first-class products, first-class service to our customer.
