Cantry MARBLE &GRANITE BLOCK CUTTING MACHINE 2200

Cantry MARBLE &GRANITE BLOCK CUTTING MACHINE 2200 thumbnail-1
Cantry MARBLE &GRANITE BLOCK CUTTING MACHINE 2200 photo-1
US$ 20,000 - 21,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Stone Cutting Machine
Use:
Granite
Contact Supplier Request Quote Chat Now
Fujian Hailong Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Stone Cutting Machine
Use Granite
Production Capacity 300m2/Day
Place of Origin Fujian, China
Brand Name HAILONG
Model Number LMQ-2200/2500/3200
Voltage According to cutsomer demand
Power(W) 50.2KW
Dimension(L*W*H) 7800*4000*6500
Weight 10500KG
Certification CE/CNAS/ISO9001/IAF
Warranty 6 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. 1 blades cutter (5.5~6.5mm thickness)
2.300 squre meter/ day production
3.blade size: 2200-3000


Cantry MARBLE &GRANITE BLOCK CUTTING MACHINE 2200Cantry MARBLE &GRANITE BLOCK CUTTING MACHINE 2200Cantry MARBLE &GRANITE BLOCK CUTTING MACHINE 2200
Product Description

QDQ-B-2500/QDQ2800/QDQ3200

BRIDGE MULTI BLADES BLOCK CUTTING MACHINE



Function:

This machine is applicable for cutting stone block into slabs and tiles, featured by precise cutting, high efficiency and easy operation.  It can cut with combination of large, middle-size and small blades or single large blade, ideally used for cutting blocks.



Production Ability:

Granite of medium rigidity: 200M2 / 24h

Granite of hard rigidity:150 M2 / 24h

Marble: 110-120M2 / 24h



Features:

This machine adopt the double pillars and single cross bridge structure to cut the slab. The main spindle use the doubt axis design and make sure the slab can be cut in one time and no need to stop cutting during the process. The Machine usually only holds only one blade but you can also hold 3 big and 3 small blades. This machine is perfect to cut the big size block.

The blade splitting can be controlled by time automaticly.

The track length:6 meters

The table:2000x2000mm

Production:70-90m2/8hours



TECHICAL PARAMETER

Item No.

LMQ-2200

LMQ-2500

LMQ-3000

Blade size

2200

2500

3000

Blade quantity

Φ2200X1pc

Φ1600x1pc

Φ940x1pc

Φ2500



Φ3000

Blade thickness

6.5

8

8

Main motor power

30

30

37

Table size

2000x2000

2000x2000

2000x2000

Max process size

3000x2000x950

3000x2000x1100

3400x2000x1350

Machine size

6600x6000x4800

6600x6000x4800

7000x4700x6000

Water consumption

6

6

6

weight

9000

9000

12000






Packaging & Shipping

 Sea worthy packaging, fully wrapped with waterproof membrane and air bubbles

Two units in one 40’ GP container

Delivery time :15-45 days from production and 1-2weeks from stock

Guaranty time for elements: half an year

Payment: 30% by T/T in advance as deposit, 70% upon dispatch
