Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > Solar Plant 150 Watt Solar Panel

Solar Plant 150 Watt Solar Panel

Solar Plant 150 Watt Solar Panel thumbnail-3

Solar Plant 150 Watt Solar Panel photo-1

Solar Plant 150 Watt Solar Panel photo-2

Solar Plant 150 Watt Solar Panel photo-3

US$ 0.52 - 0.68 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Hubei, China

Brand Name:

Model Number:

SUN-M150P

Contact Supplier Request Quote Chat Now

Hubei Eternal Solar Energy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Hubei, China

Brand Name YH

Model Number SUN-M150P

Material Polycrystalline Silicon

Size 1480*680*35mm

Number of Cells 36pcs

Max. Power 150W

Product Description

Electrical characteristics

Under STC (irradiance 1000W/m2, module temperature 25℃, AM1.5)

Model	SUN-M150P
Maximum Power at STC(Pmax)	150W
Optimum Operating Voltage(Vmp)	18V
Optimum Operating Current(Imp)	8.33A
Open-circuit Voltage(Voc)	21.3V
Short-circuit Current(Isc)	9.17A
Operating Temperature	-40℃+85℃
Maximum System Voltage	1000Vdc(IEC)600Vdc(UL)
Maximum Series Fuse Rating	10A

Mechanical Characteristics

Frame: anodized aluminum alloy

Junction box: IP65 rated

Wind loads: 2400 Pascal certified

Output cables: double insulated solar cable, MC or compatible connection

Security data

High voltage test: 3000V DC/max, 50MA

Surface maximum load capacity: 200kg/sq.m

Allowable hail load: 225mg steel ball down from 2m height

Certifications

Warranty

5 years material and workmanship warranty

10 years 90% power output

25 years 80% power output

. Quality insurance by 6 different China Insurance companies.

FAQ

1. Q: Are you a factory or trading company?

A: We are a factory.

2. Q: Where is your factory located? How can I visit there?

A: Our factory is located in Jianshi, Hubei, China, near Wuhan. You are warmly welcomed to visit us .And before you take off from your country, please let us know. We will show you the way, or arrange time to pick you up if possible.

3. Q: Do you provide free sample?
A: Usually we do not offer free sample.

4. Q: Can the price be cheaper?

A: Of course, you will be offered a good discount for big amount.

5. Q: Could you print our company LOGO on the nameplate and package?

A: Yes, we can do that.

6. Q: Do you accept custom design on size?

A: Yes, if the size is reasonable.

Packaging & Shipping
