Electrical characteristics
Under STC (irradiance 1000W/m2, module temperature 25℃, AM1.5)
| Technical Data | ||||||||
| MP-29P60 SERIES | ||||||||
| Polycrystalline cells | 60 | |||||||
| Max system voltage | 1000V | |||||||
| Electrical Data | ||||||||
| Under STC ( Standard Test Conditions:1000W/m2 25℃, AM1.5) | ||||||||
| Maximum Power Output[Pmax] | 225Wp | 230Wp | 235Wp | 240Wp | 250Wp | |||
| Tolerance | ±3% | |||||||
| Maximum Power Voltage [Vmax] | 29.62V | 29.94V | 29.99V | 30.5V | 30.5V | |||
| Open Circuit Voltage [Voc] | 36.62V | 36.9V | 37.05V | 37.09V | 37.09V | |||
| Maximum Power Current [Imax] | 7.6A | 7.68A | 7.84A | 7.87A | 8.19A | |||
| Short Circuit Power Current [Isc] | 8.26A | 8.27A | 8.31A | 8.4A | 9.33A | |||
| Temperature data | ||||||||
| Temperature coefficients of Pmax —0.47%℃ | -0.47% /℃ | |||||||
| Temperature coefficients of Voc | -0.38% /℃ | |||||||
| Temperature coefficients of Isc | +0.1% /℃ |
|||||||
Mechanical Characteristics
Cell type: 6 inches
Cell arrangement: 60
Dimensions (mm): 1640*992*40
Weight (kg): 19
Frame: anodized aluminum alloy
Junction box: IP65 rated
Wind loads: 2400 Pascal certified
Output cables: double insulated solar cable, MC or compatible connection
HUBEI ETERNAL SOLAR CO.,LTD. is a high-tech enterprise integrating the research, development, production and sales of solar photovoltaic products. It was established and settled in Jianshi Industrial Zone of Hubei Province in September 2007 with the registered capital of 50 million Yuan.
The products of our company contains the solar cell, solar panel, solar street light, solar garden light and other solar application series,and we supply the distributed grid-connected generation system, information intelligent power station’s design and installation service, We have implemented total industrial output value 820 million Yuan including export trade volume 20 million dollars, which contributed profits and taxes 180 million Yuan. The company have designed and installed more than 20 distributed grid-connected generation systems and the capacity more than 800KW.
The packaging process
5 years material and workmanship warranty
10 years ³90% power output
25 years ³80% power output
. Quality insurance by 6 different China Insurance companies.
