downlight with induction lamp

Specifications

downlight with induction lamp
1.60%-90% energy saving
2.power factor>0.99
3.CE CQC FCC RoHS ISO

downlight with induction lamp





Welcome your visit and please see product details belowing:



Induction lamp working principle

As a new tech of lighting products,and due to its advantages,induction lamp is not doubt the primier choice of lighting source.



Induction lamp is a fluorescent lamp that without electrodes,which relies in the fundamental principles of electromagnetic induction and gas discharge to create light.The elimination of filaments and electrodes results in a lamp of unparalleled life.Lasting 100,000 hours or 25 years,this system can outlast 100 incandescent,five HID,or five typical fluorescent lamp changes.



Light can be generated via a gas discharge through simple magnetism.Electromagnetic transformers,which consists of rings with metal coils,creates an electronic ballast.







The discharge path,induced by the coils,forms a closed loop causing acceleration of free electrons,which collide with mercury atoms and excites the electrons.As the excited electrons from these atoms fall back from this higher energy state to a lower stable level,they emit ultraviolet radiation created is converted to visible light as it passes through a phosphor coating on the surface of the tube,The unusual shape of an induction lamp maximizes the efficiency of the fields that are generated.



Features

1. Maintenance: Long lifespan 100000 hours, 5 years guaranteed and no maintenance. The induction bulb & ballasts are engineered to last for 100,000 hours. This eliminates the maintenance costs associated with constantly re-lamping;

2. Energy Savings: Reduces lighting energy consumption by 60% - 90% and Average ROI: 10-24 months, high lighting efficiency and stable luminous flux;

3. Color rendering index: CRI>80Ra, Luminous Efficiency>80lm/w,  power factor>0.99  ;

4. Working normally in wide voltage fluctuation;

5. EMC test fulfills CE, CCC;

6. Quick start at low temp. operating temp:-35^oC to +50^oC;

7. Excellent protection: ballast is protected from short-circuit, open-circuit, electricity abrupt cutoff, defective lamp tube and so on, which ensures the lifespan of the ballast.







...

...
