Help Center200w Magnetic Grow Induction Light
Related Products
200w magnetic grow induction light
Welcome your visit and pls see more product details belowing:
Induction lamp working priciple:
As a new tech of lighting products,and due to its advantages,induction lamp is not doubt the premier choice of lighting source.
Induction lamp is a fluorescent lamp that without electrodes,which relies in the fundamental principles of electromagnetic induction and gas discharge to creat light.The elimination of filaments and electrodes results in a lamp of unparalleled life.Lasting 100,000 hours or 25 years,this system can outlast 100 incandescent,five HID,or five typical fluorescent lamp changes.
Light can be generated via a gas discharge through simple magnetism.Electromagnetic transformers,which consists of rings with metal coils,creats an electronic ballast.
The discharge path,induced by the coils,forms a closed loop causing acceleration of free electrons,which collide with mercury atoms and excites the eletrons.As the excited electrons from these atoms fall back from this higher energy state to a lower stable level,they emit ultraviolet radiation created is converted to visible light as it passes through a phosphor coating on the surface of the tube,The unusual shape of an induction lamp maximizes the efficiency of the fields that are generated.
Low frequency induction lamp technical data
Wattage |
Effective flum (Plm) |
Lumens (LM) |
Rate life (H) |
CRI (Ra) |
Color temp. (K) |
40W |
3900~4600 |
3000~3400 |
100000 |
>82 |
2700 3500 4000 5000 6500 |
60W |
6200~8900 |
4200~5800 |
100000 |
>82 |
|
80W |
9600~11100 |
6000~6800 |
100000 |
>82 |
|
100W |
12600~14800 |
7500~8500 |
100000 |
>82 |
|
120W |
15500~18000 |
9000~10200 |
100000 |
>82 |
|
150W |
19500~22000 |
11250~12750 |
100000 |
>82 |
|
200W |
28000~30000 |
15400~16600 |
100000 |
>82 |
|
250W |
30000~33000 |
17500~22000 |
100000 |
>82 |
|
300W |
35000~42000 |
22500~25500 |
100000 |
>82 |
Low frequency induction lamp electric technical data
Wattage |
Main frequency |
Power factor |
Input frequency |
Input current (A) |
Working temp. (°C) |
40W |
230KHZ |
>0.99 |
50Hz/60Hz |
0.23 |
-35°C~+50°C |
60w |
230KHZ |
>0.99 |
50Hz/60Hz |
0.31 |
-35°C~+50°C |
80W |
230KHZ |
>0.99 |
50Hz/60Hz |
0.42 |
-35°C~+50°C |
100w |
230KHZ |
>0.99 |
50Hz/60Hz |
0.44 |
-35°C~+50°C |
120W |
230KHZ |
>0.99 |
50Hz/60Hz |
0.60 |
-35°C~+50°C |
150W |
230KHZ |
>0.99 |
50Hz/60Hz |
0.74 |
-35°C~+50°C |
200W |
230KHZ |
>0.99 |
50Hz/60Hz |
1.06 |
-35°C~+50°C |
250w |
230KHZ |
>0.99 |
50Hz/60Hz |
1.25 |
-35°C~+50°C |
300w |
230KHZ |
>0.99 |
50Hz/60Hz |
1.30 |
-35°C~+50°C |
Advantages
- Super long service life,5years guaranteed and low maintenance required
- Energy saving,high lighting effiency and stable luminous flux
- Whole color temp. rendering from 2100K-6500K,color rending index:CRI>80Ra,luminous efficiency>80ml/w,high power factor:0.99
- Ballast working frequency:230KHz,voltage:90V-150V &165V-270V AC,12V&DC24V,Wattage:15W-300w
- Working normally in wide voltage fluctuation
- EMC test fulfill CE,CCC
- Instant start up at low temp. is -35°C to +50°C
- Excellent protection:ballast is protected from short-circuit, electricity abrupt cut off, defective lamp tube and so on,which ensures a regular working lifespan.
...
