Specifications
tunnel light energy saving 100w1. 5year guaranteed
2. power factor > 0.99
3. 90V-270V,2700K-6500K
4. FCC, CE,RoHS
tunnel light energy saving 100w
Welcome your kind visit and pls see more product details belowing:
Induction lamp working principle
As a new tech of lighting products,and due to its advantages,induction lamp is not doubt the premier choice of lighting source.
Induction lamp is a fluorescent lamp that without electrodes,which relies in the fundamental principles of electromagnetic induction and gas discharge to create light.The elimination of filaments and electrodes results in a lamp of unparalleled life.Lasting 100,000 hours or 25 years,this system can outlast 100 incandescent,five HID,or five typical fluorescent lamp changes.
Light can be generated via a gas discharge through simple magnetism.Electromagnetic transformers,which consists of rings with metal coils,creates an electronic ballast.
The discharge path,induced by the coils,forms a closed loop causing acceleration of free electrons,which collide with mercury atoms and excites the electrons.As the excited electrons from these atoms fall back from this higher energy state to a lower stable level,they emit ultraviolet radiation created is converted to visible light as it passes through a phosphor coating on the surface of the tube,The unusual shape of an induction lamp maximizes the efficiency of the fields that are generated.
Induction lamp details:
1. 5 year guaranteed, 100000 hours lifespan
2. power factor > 0.99
3. CRI > 80Ra
4. luminous efficiency>80m/w
5. FCC, CE, RoHS certificated;
6 Voltage: 90V-270V
7. Frequency: 230KHz;
8. Color temp: 2700K-6400K
9. Power: 40W-200W
10. 60%-90% energy saving.
Tunnel light features:
1.One piece aluminium fixture in whole,with aluminium side welding,high IP rating,corrosion resistent,solid and durable.
2.High temp. resistant gas-tight silicon subber seal,IP65 rating
3.Folding cover configuration with wiring installed inside,while with easy installation and maintenance.
4.Pure aluminium mirror reflector,toughened flat glass cover,symmetrical and large lighting distribution,high lighting efficiency
....
