Hybrid ceramic self-aligning ball bearing 1310K+H310 with tapered bore
Self-aligning ball bearing has two rows of steel balls, a inner ring that has two raceways and a outer raceway in the inner spherical shape, and is provided with the function of self-aligning. The bearing can automatically compensate the concentricity error caused by the shaft deflection and housing deformation, thus suitable to the applications where the bearing seat hole can not guarantee strict concentricity. so it can still works as long as the relevant gradient between the center line of the inner ring and the same of the outer ring is within the range of 1 ° to 2.5 ° when the shaft is bent or tilted under pressure. There are two types of self-aligning ball bearings, i.e., cylindrical bore and tapered bore bearings. The taper ratio of tapered bore bearings is 1:1 or 1:30.
Self-aligning ball bearings are mainly used to carry heavy loads and impact loads, and apply to industries such as textile industry, mining, petroleum, paper making, cement, etc. and general machinery .
|
Model Number
|
1310K+H310 |
|
Structure
|
Self-aligning |
|
Type
|
Ball |
|
Bore Size
|
50 mm |
|
Outside Diameter
|
110 mm |
|
Width
|
62 mm |
|
Weight
|
1.74 kg |
|
Seals Type
|
Open,ZZ,2RS,RS |
|
Material
|
Ring Material Chrome Steel ,Carbon steel,Stainless steel |
|
Cage material
|
Nylon ,steel , brass |
|
Clearance
|
C0,C2,C3,C4,C5 |
|
Vibration
|
Z1V1,Z2V2,Z3V3 |
|
Precision Rating
|
P0,P6,P5,P4,P2 |
|
Greese
|
As you requirement, such as SRL ,PS2, Alvania R12 and so on . |
|
Guarantee
|
One year. |
Application |
Home appliances, low noise and high speed electric motors, |
automotive components, pumps, machinery. | |
|
Certifications
|
ISO 9001:2013 |
|
Package
|
Single box or according to buyers requirement . |
|
Place of Origin
|
China (Mainland) |
|
MOQ
|
1PCS |
Service |
(1) Prompt Delivery |
(2) OEM | |
(3) Good Service Offered | |
(4) Buyer Label Offered | |
|
Payment Term
|
TT,Paypal or Western Union |
|
Port
|
Guangzhou,Shanghai or your requirement |
Details |
1,Low price |
2.Low vibration | |
3.high rolling accuracy |
