Help CenterTOA1000 1550nm Optical Amplifier 3U Structure
Related Products
-
Forward Optical Receiver Module TFR1000E AGC 3 U With Network MonitoringNegotiableMOQ: 1 Piece -
TRR1000D 2-way AGC Return Optical ReceiverNegotiableMOQ: 1 Piece
-
TOA1000 Original JDSU Pump EDFA Optical AmpifierNegotiableMOQ: 1 Piece
-
Optical Platform OPTIVO Optical Platform 4U 16 Modules Dual Power SupplyNegotiableMOQ: 1 Set
-
Professional Full-line CATV ProductsNegotiableMOQ: 1
Specifications
1.TOA1000 1550nm optical ampifier2.Using worldwide famous pump inside
3.High stability
4.Very low noise
5.ATC circuit
Summarize
TOA1000 1550nm optical amplifier is the best choice of 1550nm transmission system networking products. It combines with TNE1000 optical platform rack, TPS1000 power to consist excellent performance optical headend transmission equipment.
TOA1000 1550nm optical amplifier adopts well-known international brand stabilized pump source, low noise figure, high saturated output optical power and stable. It can be used for cable TV images, digital TV signals, telephone voice signals and data signals over long distance, large area transmission.
Built-in rack microprocessor can real-time monitor the pump working status and input/output power. When the optical fiber amplifier work disorders, output corresponding alarm information. When a serious warning appears, it will automatically turn-off pump laser to protect the amplifier; when enter matt, it will automatically turn-off too.
This amplifier adopts radiator-style overall structure, high strength, excellent heat dissipation.
Features:
* Using good performance and high reliability pump
* Very low Noise figure
* Excellent pump ATC circuit
* Display the working status by LCD, easy to operate
* Excellent heat dissipation to guarantee the long term working
Diagram
Specifications:
Item |
Unit |
Specification |
Remark |
|
Optical Wavelength |
nm |
1535~ 1565 |
|
|
Input optical power range |
dBm |
-3~ +10 |
|
|
Output optical power range |
dBm |
10~ 24 |
|
|
Noise |
dB |
≤5.0 |
Input optic power is 0dBm |
|
Return loss |
Input return loss |
dB |
≥45 |
|
Output return loss |
dB |
≥45 |
|
|
Pump leakage power |
Inlets pump leakage power |
dBm |
≤-30 |
|
Outlet pump leakage power |
dBm |
≤-30 |
|
|
C/N |
dB |
≥51 |
|
|
C/CTB |
dB |
≥63 |
|
|
C/CSO |
dB |
≥63 |
|
|
Operating Temperature |
° C |
-5~ +55 |
|
|
Operating Humidity (max) |
|
95% |
|
|
Storage Temperature Range |
° C |
-30~ +70 |
|
|
Storage Humidity(max) |
|
95% |
|
|
