Specifications
1)Used for circulation and boost cold & hot water2)High pressure system
3)Stainless casing
4)Mechanical seal
5)No leakage
BPG stainless steel multi-stage high pressure water pump
<1>Pump outline:
Model BPG multi-stage pipeline centrifugal pump is a new generation product designed and made by this Co.on the basis of the excellent pump types both domestic and overseas and combining the requirements of use and the related fire-fighting standards and following the standard of JB/TQ6435-92.
This pump uses a vertical,sectional and stainless steel casing structure to have both inlet and outlet on a same level,of a same aperture and capable of being mounted in a pipeline just as a valve and collects the merits of the high pressure of a multi-stage pump,a less land area of a vertical pump and convenient installation of a pipeline pump and,due to the excellent hydraulic model it adopts,also features a high efficiency,energy-saving,stable running ect.,in addition,because of the wearable mechanical seal it uses as the shaft seal, it has no leak and a long duration of use.
<2>Technical data:
a)Flow:4-2400m3/h
b)Head:8-150m
c)Medium temperature:-20-120oC
d)Operation pressure:≤1.6Mpa
<3>Features:
a)Compact structure
b)Stable running, low noise
c)No leakage
d)Convenient operation
e)Viewing from the inlet of the pump, the outlet of it can
be mounted in one of the three ways, horizontally leftward,
vertically upward and horizontally rightward
<4>Application:
a)water supply and drainage in industries and cities
b)boost water-feeding for high buildings
c)garden irregation
d)fire-fighting water supply boost
e)remote distance transportation
Structure of BPG pump:
Other Advantage Pump:
AFP submersible sewage pump
AY series centrifugal oil pump
BPL series single-stage singel-suction vertical centrifugal pump
BPW series single-stage single-suction horizontal centrifugal pump
BPX series low-carbon composite centrifugal pump
D series multi-stage sectional centrifugal pump
GDL series multi-stage pipline centrifugal pump
LP(T) series vertical drainage pump
QZ,QH series axial-flow pump
Z(H)LB series vertical axial-(mixed)-flow pump
BPO series single-stage double-suction open centrifugal pump
WFY non-negative pressure water-supply equipment
Company introduction:
Shanghai Bangpu Industrial Group Co., Ltd. is a group enterprise specializing in the research and production of various fluid transfer equipments. Our main products include pumps,valves,motors,electric series and water supply system package. Waste water treatment, environmental protection equipments, accessories are also within our main business area. In 2008, Bangpu Group acquired Shanghai Electrical Machinery Factory Co., Ltd. and embarked on a higher speed growing path.
Manufacture view:
Project Case:
