Specifications

thin-section bearing:
1. High accuracy
2. Low noise
3. Oil Preservative
4.be customized

6805ZZ Bearing 25x37x7 Shielded Ball Bearings



• 6805ZZ Shielded Ball Bearing , bearing is made from Chrome Steel, bearing has 2 Metal Shields to protect the bearing from dust or any possible contamination, this bearing is self lubricated (bearing is already greased).

  • Item: 6805ZZ Ball Bearing
  • Type: Deep groove ball bearings
  • Closures: Metal Shields
  • Quality: Electric Motor Quality
  • Bearing dimensions: 25mm x 37mm x 7mm
  • Inner Diameter: 25mm
  • Outer Diameter: 37mm
  • Width: 7mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 4,300 N
  • Static load rating Cor: 2,940 N
  • Limiting Speed:
    • Grease Lubrication: 18,000 RPM
  • Equivalents: 61805-2Z and 61805Z Bearings

Specifications of some thin section ball bearings



KCseries				Weight(kg)	Interchang
Dimension(inch)		Basic Cap.N			KAYDON
d	D	Cor	Cr
6.000	6.750	13650	5070	0.295	KC060CP0
6.500	7.250	14710	5330	0.312	KC065CP0
7.000	7.750	15780	5560	0.340	KC070CP0
7.500	8.250	16850	5820	0.360	KC075CP0
8.000	8.750	17910	6050	0.387	KC080CP0
9.000	9.750	20050	6530	0.450	KC090CP0
10.000	10.750	22180	6980	0.481	KC100CP0
11.000	11.760	24310	7420	0.526	KC110CP0
12.000	12.750	30720	8670	0.567	KC120CP0
14.000	14.750	30720	8670	0.689	KC140CP0
16.000	16.750	35030	9470	0.785	KC160CP0
18.000	18.750	39290	10220	0.880	KC180CP0
20.000	20.750	43560	10980	0.980	KC200CP0
