Help Center6816-2RS Sealed Bearing 80x100x10 Ball Bearings
Related Products
-
Bearing 65x85x10mm Open Ball Bearing 6813US$ 0.2 - 200MOQ: 10 Pieces -
6814 Ball Bearing 70x90x10 Open Ball BearingsUS$ 0.2 - 200MOQ: 10 Pieces
-
6815 Bearing 75x95x10 Open Ball BearingsUS$ 0.2 - 200MOQ: 10 Pieces
-
6817 Bearing 85x110x13 Open Ball Bearings/6817 Thin-section BearingUS$ 0.2 - 200MOQ: 10 Pieces
-
VG042CP0 Thin Section Bearing 4 1/4"x6 1/4"x1" Inch Open Ball BearingsUS$ 0.2 - 200MOQ: 10 Pieces
Specifications
thin-section bearing:1. High accuracy
2. Low noise
3. Oil Preservative
4.be customized
6816-2RS Sealed Bearing 80x100x10 Ball Bearings
-
6816-2RS Bearing is double sealed, radial and deep groove ball bearing, 6816-2RS bearing is made of Chrome Steel with chrome steel balls and steel cage, 6816-2RS bearing is closed with rubber seals to protect the bearing from dust or any possible contamination, bearing is sealed and self lubricated, the quality is set to EMQ (electric motor quality) to ensure high speed, 6816-2RS bearing is lubricated with grease.
- Item: 6816-2RS Ball Bearing
- Type: Deep groove radial ball bearing
- Lubrication: Self Lubricated (Grease) Bearing
- Closures: Double sealed with rubber seals RS/RS1/2RS1
- Material: Chrome Steel
- Balls: Chrome Steel
- Cage: Steel
- Quality: Electric motor quality
- Radial Clearance: C0
- Equivalents: 61816-2RS1 and 6816RS Bearing
- Inner Diameter: 80mm
- Outer Diameter: 100mm
- Width: 10mm
- Size: 80 x 100 x 10 mm
- Highest Temperature: 356 (degrees fahrenheit)=180 (degrees Celsius)
- Quantity: One Bearing
Specifications of some thin section ball bearings
| KCseries | Weight(kg) | Interchang | |||
| Dimension(inch) | Basic Cap.N | KAYDON | |||
| d | D | Cor | Cr | ||
| 6.000 | 6.750 | 13650 | 5070 | 0.295 | KC060CP0 |
| 6.500 | 7.250 | 14710 | 5330 | 0.312 | KC065CP0 |
| 7.000 | 7.750 | 15780 | 5560 | 0.340 | KC070CP0 |
| 7.500 | 8.250 | 16850 | 5820 | 0.360 | KC075CP0 |
| 8.000 | 8.750 | 17910 | 6050 | 0.387 | KC080CP0 |
| 9.000 | 9.750 | 20050 | 6530 | 0.450 | KC090CP0 |
| 10.000 | 10.750 | 22180 | 6980 | 0.481 | KC100CP0 |
| 11.000 | 11.760 | 24310 | 7420 | 0.526 | KC110CP0 |
| 12.000 | 12.750 | 30720 | 8670 | 0.567 | KC120CP0 |
| 14.000 | 14.750 | 30720 | 8670 | 0.689 | KC140CP0 |
| 16.000 | 16.750 | 35030 | 9470 | 0.785 | KC160CP0 |
| 18.000 | 18.750 | 39290 | 10220 | 0.880 | KC180CP0 |
| 20.000 | 20.750 | 43560 | 10980 | 0.980 | KC200CP0 |
We are a Energetic Bearing company with more than 10 years experience in Shandong factory .
We mainly deal in : Deep groove ball bearing , Angular contact ball bearing , Taper roller bearing , Cylindrical roller bearing , Pillow Block bearing , Ceremic Ball bearing , OEMService also welcomed .
Customers Spoke highly to our high quality with competitive price , and good service . We always stick to the principle : “Treat customers wholeheartly” and making progress .
