6816-2RS Sealed Bearing 80x100x10 Ball Bearings

Original package, Neutral package.(Single package), Wooden package + pallet; Carton package + pallet. Or as your requirements

Specifications

thin-section bearing:
1. High accuracy
2. Low noise
3. Oil Preservative
4.be customized

 6816-2RS Sealed Bearing 80x100x10 Ball Bearings



• 6816-2RS Bearing is double sealed, radial and deep groove ball bearing, 6816-2RS bearing is made of Chrome Steel with chrome steel balls and steel cage, 6816-2RS bearing is closed with rubber seals to protect the bearing from dust or any possible contamination, bearing is sealed and self lubricated, the quality is set to EMQ (electric motor quality) to ensure high speed, 6816-2RS bearing is lubricated with grease.

  • Item: 6816-2RS Ball Bearing
  • Type: Deep groove radial ball bearing
  • Lubrication: Self Lubricated (Grease) Bearing
  • Closures: Double sealed with rubber seals RS/RS1/2RS1
  • Material: Chrome Steel
  • Balls: Chrome Steel
  • Cage: Steel
  • Quality: Electric motor quality
  • Radial Clearance: C0
  • Equivalents: 61816-2RS1 and 6816RS Bearing
  • Inner Diameter: 80mm
  • Outer Diameter: 100mm
  • Width: 10mm
  • Size: 80 x 100 x 10 mm
  • Highest Temperature: 356 (degrees fahrenheit)=180 (degrees Celsius)
  • Quantity: One Bearing

Specifications of some thin section ball bearings



KCseries				Weight(kg)	Interchang
Dimension(inch)		Basic Cap.N			KAYDON
d	D	Cor	Cr
6.000	6.750	13650	5070	0.295	KC060CP0
6.500	7.250	14710	5330	0.312	KC065CP0
7.000	7.750	15780	5560	0.340	KC070CP0
7.500	8.250	16850	5820	0.360	KC075CP0
8.000	8.750	17910	6050	0.387	KC080CP0
9.000	9.750	20050	6530	0.450	KC090CP0
10.000	10.750	22180	6980	0.481	KC100CP0
11.000	11.760	24310	7420	0.526	KC110CP0
12.000	12.750	30720	8670	0.567	KC120CP0
14.000	14.750	30720	8670	0.689	KC140CP0
16.000	16.750	35030	9470	0.785	KC160CP0
18.000	18.750	39290	10220	0.880	KC180CP0
20.000	20.750	43560	10980	0.980	KC200CP0
