DU SF-2 10mm Bushings Sliding Bushings DX bush for automotive industry bushing
- 1500000 Piece / Pieces per Month
- Shanghai
- T/T
- JF800 10mm Bushings Sliding Bushings DX bush for automotive industry bushing
- FB090 10mm Bushings Sliding Bushings DX bush for automotive industry bushing
- FB092 10mm Bushings Sliding Bushings DX bush for automotive industry bushing
- SF-1Sliding Bearing,SF-1 bushing bearing
- SF-1B Bronze Bearing bushing/ Bronze sleeve bearing
- SF-1P Reciprocating Motion Bearing/SF bearing bushings
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | NSK NTN HRY OEM | Model Number: | DU,DX,FB090,FB092,JDB,SF-1,SF-2 |
Type: | Other, Sleeve, bush | Material: | HLDB-2Y HLDB-10Du HLDB-800 |
Packaging Details
Products packed by plastic bag, each bag contain 500pcs or 5kg Max, packed Cartons max 20kgs each. Delivered by Wooden package or Iron cage / Pallet as requested, Standard Size 800x800x1200; Max G.W. 800kgs
Product Description
Specifications
1.Good anti-wear,low friction2.low noise,long useful time
3.direct Du bush supplier
4. High Precison, Low Friction
1.POM thickness 0.30~0.50 mm 2. Sintered bronze powder thickness 0.20-0.35mm 3. Low-carbon steel 4. Copper/Tin plating thickness 0.002mm
Equipment
CNC machining,EDM electrode,Lathe Machining, drilling machine,NC Milling machine ,RHC heat treatment,Mirror surface,Inner/Outer grinding machine and so on .
|
Max.load | Static | 250N/mm² |
Lower speed | 140N/mm² | |
Roatating oscillating | 70N/mm² | |
Max.PV(dry running) | 2.8N/mm².m/s | |
Temp.limit | -195°C to+ 280°C | |
Friction coefficient | 0.05~0.25 | |
Max.speed | Dry friction | 2.5m/s |
Oil lubrication | 5.0m/s | |
Thermal condustivity | 4W/m.k | |
Coefficient of thermal expansion | 11X10-6/K | |
Initial assembly must be painted in the oil hold in the grease. |
Sleeve Bearings:
Model No. | Min. I.D. | Min.O.D. | Max.I.D. | Max.O.D. | Max. Length |
DU,SF-1 | 6mm | 8mm | 300mm | 305mm | 100mm |
DX,SF-2 | 10mm | 12mm | 300mm | 305mm | 100mm |
JF800 | 10mm | 12mm | 173mm | 180mm | 100mm |
FB090 | 10mm | 12mm | 300mm | 305mm | 100mm |
FB092 | 10mm | 12mm | 300mm | 305mm | 100mm |
JDB,JCB | 8mm | 12mm | 160mm | 180mm | 150mm |
FU | 1.5mm | 3mm | 50mm | 70mm | 70mm |
JGB | 1.5mm | 3mm | 300mm | 320mm | 100mm |
I.D. = inner diameter
O.D. = Outer diameter
Flange Bearings:
Model No. | Min. I.D. | Min.O.D. | Max.I.D. | Max.O.D. | Min.F.D. | Max.F.D. | Max. Length |
DU,SF-1 | 6mm | 8mm | 40mm | 44mm | 12mm | 53mm | 40mm |
JF-800 | 40mm | 46mm | 95mm | 105mm | 60mm | 144mm | 127mm |
FB090 | 25mm | 28mm | 300mm | 305mm | 35mm | 340mm | 90mm |
FB092 | 25mm | 28mm | 300mm | 305mm | 35mm | 340mm | 90mm |
JDB | 10mm | 14mm | 120mm | 140mm | 22mm | 170mm | 100mm |
FU | 6mm | 12mm | 50mm | 60mm | 14mm | 70mm | 70mm |
JGB | 6mm | 12mm | 300mm | 320mm | 35mm | 340mm | 130mm |
I.D. = inner diameter
O.D. = Outer diameter
F.D. = Falnge diameter
Color:Black, Silver, Red, Blue, Gold, Oliver, White and etc.
material:Brass,Bronze,Copper,Hardened Metals and etc.,
Surface treatment: Polishing ,hardening, carburizing, anodizing, clear anodizing,black anodizing ,chrome plating, black oxide coating, nickel plating, zinc plating, nitriding, degreasing, painting or depend on clients' requirement
Feature:Strict QC and reliable quality.
Special purpose: Used in various Metal stamping,Auto,Motor, Machinery, Electric Tools, Sports Apparatus, office equipment , toys, Fan,and automatic machine,Textile machine, Pump,Agricultural machinery,Machine tool,window ,sliding door, etc
Main markets: cccccc and all over the world.
Equipment:CNC machining,EDM electrode,Lathe Machining, drilling machine,NC Milling machine ,RHC heat treatment,Mirror surface,Inner/Outer grinding machine and so on .
primary Competitive Advantages
1. Advanced machinery & excelent engineering team,competitive price.
2.made in various materials according to cilent's request.
3.non-standard machining parts are available upon request.
4.Small quantity order acceptable.
5.High accuracy with 0.002.
Packaging Details:Products packed by plastic bag, each bag contain 500pcs or 5kg Max, packed Cartons max 20kgs each. Delivered by Wooden package or Iron cage / Pallet as requested, Standard Size 800x800x1200; Max G.W. 800kgs
Delivery Time:Within 10-20days after order confirmation.
Company Profile
Wuxi Hangruiyu Bearing Co., Ltd. is a manufacturer of bearings with well-equipped testing equipment and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in large machinery, petrochemical industry, mine, metallurgy and other machinery industry supporting products.
Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.
We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!
