Specifications
bronze base bushing SF-1Blow friction coefficient ,
good corrosion resistance,
self-lubrating ,
low noise
Good corrosion resistance bronze base bushing SF-1B
SF - 1 B based bearing bronze, tin bronze as base, sintered bronze spherical powder, surface rolling PTEE and high temperature resistant filler material.
A mixture of PTFE and lead in sports can form a good protection of grinding axis transfer film.
1. sintering layer and copper substrate with good thermal conductivity, can rapidly generate heat in the process of transfer operation.
2. copper with self-lubricating performance and can be used for the part of the long-term operation and can't stop.
3. base copper has good corrosion resistance, can be applied to weak acid, strong alkali.
4. with good bearing capacity.
Technical Data:
Specific load capacity (static) |
≤ 250 [ N/mm² ] |
|
Specific load capacity (dynamic) |
≤ 140 N/mm² at low speeds |
|
Specific load capacity(rotating oscillating) |
≤60N/m m² |
|
Friction value |
0.03 to 0.25 µ |
|
Temperature |
-200 to +280 [ °C ] |
|
Max. dry running Pv (Short-term operation) |
3.6N/m m² *m/s |
|
Max. dry running Pv (Continuous operation) |
1.8N/m m² *m/s |
|
Max. speed (dry running) |
2m/s |
|
Max. speed (Hydrodynamic operation) |
>2m/s |
|
Typical application
products have been widely used in metallurgy, iron and steel industry high temperature furnace of steel ring part, cement grouting pump, screw conveyor, port machinery and ship etc.
Bushing we deal in
SF-1 series bushing , SF-1 series bushing lead free , SF-2 series bushing, bimetal bushing , Copper bushing , and so on .
