Home > Electrical & Electronics > Cable Parts > Cable Sleeve > 35kV Bus Bar Tube

35kV Bus Bar Tube

US$ 1 - 9 MOQ: 100 Meters

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

UPM

Model Number:

S1(n)-35

Contact Supplier Request Quote Chat Now

Union Polymer Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name UPM

Model Number S1(n)-35

Type Heat Shrinkable

Material PE

Specifications

24-36kV
Red and black busbar heat shrink tube
flame retardant or non flame retardant
Rachem BBIT/BPTM

Bus Bar Insulating Heat Shrinkable Tubing

Voltage Class 1kV~36kV

Ideal for high and low voltage bus bar insulation

Medium and heavy wall heat shrinkable tubing for protection and insulation of bus bar against accidents caused by electrified bare bus bar.

Applications

Bus bar insulation and protection

In switchgear cabinets where space is limited and air spacing between bus bars need to be kept at minimal

Features/Benefits

Reduces bus bar clearance requirements* , allow designers more freedom in designing switchgear cabinets when space is premium

Protects against accidental flashover up to 36kV

Protects against short circuit and electrical leakage caused small animals

Protects against corrosion, dirt and other contaminants that may cause accidental flashover

Halogen Free (optional)

Flame resistant with oxygen index higher than 27 (optional)

Available in continuous length roll form for convenient and economical installation

Temperature Range

Operating Temperature : -40 ºC ~ 105 ºC

Shrink Temperature : 125 ºC

Colour

Red, Yellow, Black, Green

Product Code Cross References

Raychem : BBIT / BPTM

DSG Canusa : CBTM / CBTH

3M : BBI

Technical Details

Test item	Test Standard	Typical Performance
Tensile strength	ASTM D2671	≥10 Mpa
Break down elongation	ASTM D2671	≥400 %
Tensile strength after aging	ASTM D2671,	≥10 Mpa
break down elongation after aging (136 for 168h)	ASTM D2671	≥400 %
Flame retardant	ASTM D2863	Oxygen Index ≥27
Dielectric strength	ASTM D2671	≥15 kV/mm
Heat shock (200 for 4h)	ASTM D2671	no drop, no flow
Low temperature flexibility (-40 for 4h)	ASTM D2671	no cracking
Water absorption	ASTM D570 A	≤0.5 %
Copper corrosion (158 for 168h)	ASTM 2671	pass
Long term ageing/ elongation at break	IEC 60684-2	≥175%
Resistance to selected fluids: Tensile strength Elongation at break	IEC 60684-2	>8Mpa >250%
