Kynar PVDF Electrical Heat Shrink Tubing

US$ 1.5 - 8 MOQ: 100 Meters

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

UPM

Model Number:

S5-PVDF

Union Polymer Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name UPM

Model Number S5-PVDF

Type Heat Shrinkable

Material PE

Kynar PVDF electrical Heat Shrink Tubing

1.High temperature protection
2.Excellent abrasion resistance
3.Excellent chemical and solvent resistance

Standard Specifications:
Inner packing:
Plastic packing

Outer packing:
Carton

Technical Details

Test Item		Test Method	Typical Value
Performance temperature range		IEC 216	-55°C to 175°C
Before aging	Tensile strength	ASTM D638	Min. 35MPa
	Break down elongation	ASTM D638	Min. 150%
After aging	Tensile strength	180°C/168h	No lower than 70% before aging
	Break down elongation
Distortion		150°C/h	Max. 50%
Heat resistance		300°C/h	No cracking
Low temperature resistance		-55°C/4h	No cracking
Elasticity		180°C/168h	No cracking
Incision modulus		--	Min. 84.4MPa
Dielectric strength		ASTM D2671	Min. 25kV/mm
Volume Resistivity		ASTM D876	Min. 10¹³Ω .cm
Copper corrosion		180°C/168h	No Corrosion
Copper stability		180°C/168h	Stable
Flame retardant		VW-1	Pass

Product Selection (S5 with Shrink Ratio 2:1)

Product Code	Min wall thickness after free recovery(mm)	Standard Package(m/roll)
S5-Φ1.2	0.20	200
S5-Φ1.6	0.20	100
S5-Φ2.4	0.23	100
S5-Φ3.2	0.23	100
S5-Φ4.8	0.23	1.22
S5-Φ6.4	0.28	1.22
S5-Φ9.5	0.28	1.22
S5-Φ12.7	0.28	1.22
S5-Φ19.1	0.40	1.22
S5-Φ25.4	0.40	1.22
S5-Φ38.1	0.40	1.22
S5-Φ50.8	0.45	1.22
