Green/yellow heat shrink sleeve for wire/cable marks
USD $0.01 - $9.99
/ Meter
1000 Meters(Min.Order)
- 1000 Ton / Tons per Month
- Dalian China
- T/T Credit Card
You May Like
- Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
- 3240 Epoxy Board, High-quality Insulation Material, Flexible Customization, Widely Applicable 3240 Epoxy Sheet
- Chinese Factory Electrical Insulation Brown 3025 Phenolic Bakelite Resin Cotton Cloth Fabric Laminate Board Sheet Phenolic Board
- 4x8 fiberglass sheets g10 epoxy glass fiber board g10 material
- Factory Price Bakelite Decorative HPL Press plates bakelite sheet
- Black G10 Sheet - High Quality Carbon Fiber G10 FR4 Sheets - Precision-made PCB Materials
Product Details
Place of Origin: | Liaoning, China | Brand Name: | UPM | Model Number: | S11 |
Type: | Insulation Sleeving | Material: | Composite Polymer | Application: | Low Voltage |
Rated Voltage: | 1kV | Tensile Strength: | 10.4MPa |
Product Description
Specifications
General purpose insulation of wire/cable jacket, widely used in wire bundles or cables to line identification
S11 Green/Yellow Heat Shrink Sleeve for Wire/Cable Marks | ||||
Features | ||||
Cross linked polyolefin | Operating temperature: -40~125 ℃ | |||
Co-extrusion of Green/Yellow striped color | Shrink temperature: 125 ℃ | |||
Flame retardant | Shrink Ratio:2:1 & 3:1 | |||
Excellent Flexibility | Voltage Class:1000 V | |||
Tube with adhesive linner available | RoHS compliant | |||
Dimensions | Single wall | 2:1 | ||
Reference | As supplied(mm) | After recovered(mm) | Standard length | |
UPM S11 | ID min. | ID max. | WT nom. | m/spool |
2.0/1.0 | 2.0 | 1.0 | 0.35 | 200 |
3.0/1.5 | 3.0 | 1.5 | 0.38 | 200 |
4.0/2.0 | 4.0 | 2.0 | 0.45 | 100 |
5.0/2.5 | 5.0 | 2.5 | 0.45 | 100 |
6.0/3.0 | 6.0 | 3.0 | 0.50 | 100 |
8.0/4.0 | 8.0 | 4.0 | 0.55 | 100 |
10.0/5.0 | 10.0 | 5.0 | 0.55 | 100 |
12.0/6.0 | 12.0 | 6.0 | 0.60 | 100 |
16.0/8.0 | 16.0 | 8.0 | 0.70 | 100 |
18.0/9.0 | 18.0 | 9.0 | 0.70 | 100 |
20.0/10.0 | 20.0 | 10.0 | 0.75 | 100 |
25.0/12.5 | 25.0 | 12.5 | 0.90 | 50 |
30.0/15.0 | 30.0 | 15.0 | 0.95 | 50 |
35.0/17.5 | 35.0 | 17.5 | 0.95 | 50 |
40.0/20.0 | 40.0 | 20.0 | 1.00 | 50 |
50.0/25.0 | 50.0 | 25.0 | 1.00 | 25 |
60.0/30.0 | 60.0 | 30.0 | 1.10 | 25 |
70.0/35.0 | 70.0 | 35.0 | 1.20 | 25 |
80.0/40.0 | 80.0 | 40.0 | 1.30 | 25 |
100.0/50.0 | 100.0 | 50.0 | 1.65 | 25 |
Dimensions | |||
Reference | As supplied(mm) | After recovered | Standard length |
UPM S11 | ID min. | ID max.(mm) | m |
Single wall 3:1 | |||
3/1 | 3.0 | 1.0 | 200 |
6/2 | 6.0 | 2.0 | 100 |
9/3 | 9.0 | 3.0 | 100 |
12/4 | 12.0 | 4.0 | 100 |
18/6 | 18.0 | 6.0 | 100 |
24/8 | 24.0 | 8.0 | 50 |
39/13 | 39.0 | 13.0 | 50 |
Dual wall (with adhesive liner) 3:1 | |||
12/4 | 12.0 | 4.0 | 1.22 |
18/6 | 18.0 | 6.0 | 1.22 |
24/8 | 24.0 | 8.0 | 1.22 |
39/13 | 39.0 | 13.0 | 1.22 |
ID=Internal Diameter | WT= wall thickness | ||
Technical Data | |||
Property | Test method | Values | |
Physical | Tensile strength | ASTM D2671 | ≥10.4MPa |
Breakdown elongation | ASTM D2671 | ≥300% | |
Aging (158℃/168hrs) | Tensile strength | ASTM D2671 | ≥7.3MPa |
Breakdown elongation | ASTM D2671 | ≥100% | |
Heat Shock (200 ℃/4hrs) | ASTM D2671 | No drop,no flow(outer layer) | |
Low temperature flexibility(-40 ℃/4hrs) | ASTM D2671 | No cracking | |
Electrical | Dielectric strength(2500V AC for 60s) | ASTM D2671 | ≥15 KV/mm |
Chemical | Flammability | UL224 | VW-1 |
Typical application | |||
General purpose insulation of wire/cable jacket | |||
Widely used in wire bundles or cables to Line identification | |||
Ordering | |||
Standard color : Green/Yellow striped color | |||
Standard packaging on spools , Dual wall tube in 1.22 m/pc | |||
Please specify specification, quantity when ordering | |||
Cross reference | |||
Raychem/Tyco : DCPT 2:1 |
