Electrical Cable Wire Sleeve

Electrical Cable Wire Sleeve thumbnail-1
Electrical Cable Wire Sleeve photo-1
US$ 0.09 - 9.9 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Liaoning, China
Brand Name:
UPM
Model Number:
S3
Contact Supplier Request Quote Chat Now
Union Polymer Material Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Liaoning, China
Brand Name UPM
Model Number S3
Type Heat Shrinkable
Material PE

Specifications

Flame Retardant Dual Wall Heat Shrink Tube
Adhesive coating
Flame retardant Raychem:SST
Size from 12/4 to 260mm
Waterproof

S3Flame Retardant Dual Wall Heat Shrink Tube

Voltage Class 1kV Ideal for electrical insulation and protection of outdoor electrical equipments

Dual wall, flame retardant abrasion resistant heat shrinkable tubing with adhesive liner.

Applications
  Insulation protection for outdoor electrical equipments and connections (such as hanging lamps, external lighting system, electrical cable for motors and other cabling joints) in sea-going vessel, off-shore oil platform, shipyard and harbor.
  Water sealant applications for outdoor electrical equipments
  Other applications which require mechanical protection and waterproof sealing against seawater, moisture and other common contaminates



Temperature Range
       Operating Temperature         : -55~ 105 ºC
       Shrink Temperature              : 105 ~ 135 ºC

Color: Black, Red

Certification
·Type certified by DNV
·Type Certified by CCS

Product Code Cross References
·Raychem/Tyco            : SST
·DSG Canusa            : FCFW
 3M                 : HDT



Technical Details



Test Item Test Method Typical Value
Tensile strength ASTM D2671 ≥10.4Mpa
Break down elongation ASTM D2671 ≥450%
Tensile strength after aging ASTM D2671 ≥10.4Mpa
Break down elongation after aging ASTM D2671 ≥400%
Upright combustibility ASTM D2863 FV-1
Water absorption ASTM D570 ≤0.5%
Heat shock 200 for 30min No drop, no flow
Low temperature flexibility -40 for 4h No cracking
Dielectric strength ASTM D2671 ≥15kV/mm
Peel off strength to PEX ASTM D2671 ≥30N/cm
Peel off strength to steel ASTM D2671 ≥30N/cm



Product Selection

Product

Code

Internal Diameter

Before Shrink

Internal Diameter

After Shrink

Minimum Wall Thickness

After Shrink

Standard

Length

Standard Package

(mm)

(inch)

(mm)

(inch)

(mm)

(inch)

(m)

(ft)

(pcs/carton*)

S3-Φ 12/4

12

0.5

4

0.16

2.0

0.079

1.22

48

650

S3-Φ 16/5

16

0.6

5

0.20

2.2

0.087

1.22

48

450

S3-Φ 19/6

19

0.7

6

0.24

2.5

0.098

1.22

48

350

S3-Φ 22/6

22

0.9

6

0.24

2.5

0.098

1.22

48

250

S3-Φ 25/8

25

1.0

8

0.31

2.5

0.098

1.22

48

190

S3-Φ 28/6

28

1.1

6

0.24

2.5

0.098

1.22

48

170

S3-Φ 33/8

33

1.3

8

0.31

2.5

0.098

1.22

48

130

S3-Φ 35/12

35

1.4

12

0.47

2.5

0.098

1.22

48

100

S3-Φ 40/12

40

1.6

12

0.47

2.5

0.098

1.22

48

90

S3-Φ 45/13

45

1.8

13

0.51

2.5

0.098

1.22

48

70

S3-Φ 55/16

55

2.2

16

0.63

2.7

0.106

1.22

48

60

S3-Φ 65/19

65

2.6

19

0.75

2.8

0.110

1.22

48

50

S3-Φ 75/22

75

3.0

22

0.87

3.0

0.118

1.22

48

40

S3-Φ 85/25

85

3.3

25

0.98

3.0

0.118

1.22

48

30

S3-Φ 95/25

95

3.7

25

0.98

3.0

0.118

1.22

48

25

S3-Φ 115/34

115

4.5

34

1.34

3.0

0.118

1.22

48

25



ID: Internal Diameter

Electrical cable wire sleeve
