Specifications
High Voltage MLCC 0603 0805 1206 1210 1812 2220
HV Chip MLCC 0603 0805 1206 1210 1812
Tape and Reel
High Voltage MLCC 0603 0805 1206 1210 1812 2220
China supplier of High voltage ceramic capacitor, HV chip capacitor, HV SMD MLCC offered by AnXon Electronic
Application:
1. Switching power supply
2. DC-DC converters
3. Voltage multipliers
4. Radio and TV receiver
5. Modems, Interfaces
6. Other electrical appliances where high voltage is present
Our Advantage :
1. Short lead time, quick delivery.
2. Low cost price , great quality .
3. 100% new and original Guaranty
4. Custom high voltage MLCC products available
5. Customer-oriented & Best partners
High Voltage Chip Ceramic Capacitor, HV SMD MLCC information:
Operating Temperature Range: -55°C to +125°C
Rated Voltage (V): 100V - 10KVDC (100V, 200V, 250V, 500V, 630V, 1000V, 2000V, 3000V, 4000V, 5KV, 6KV, 7KV, 8KV, 9KV, 10KV)
Capacitance Range: 0.1pF - 4.7uF
Temperature characteristic: NPO (COG), X7R, X5R, Y5V, Z5U
Case Size: 0603 (1608), 0805(2012), 1206 (3216), 1210 (3225), 1812 (4532), 2220 (5750)
Size Code |
Rated Voltage (V) |
Capacitance Range(pF) |
|
|
|
COG |
X7R |
0603 |
100V |
0.1pF ~ 820pF |
100pF ~ 10000pF |
200V |
0.1pF ~ 470pF |
100pF ~ 6800pF |
|
250V |
0.1pF ~ 470pF |
100pF ~ 6800pF |
|
0805 |
100V |
0.1pF ~ 1500pF |
100pF ~ 0.1uF |
200V |
0.1pF ~ 1500pF |
100pF ~ 22nF |
|
250V |
0.1pF ~ 1500pF |
100pF ~ 22nF |
|
500V |
0.1pF ~ 560pF |
100pF ~ 10000pF |
|
1206 |
100V |
0.1pF ~ 3300pF |
100pF ~ 0.22uF |
200V |
0.1pF ~ 2700pF |
100pF ~ 0.1uF |
|
250V |
0.1pF ~ 2700pF |
100pF ~ 0.1uF |
|
500V |
0.1pF ~ 1500pF |
100pF ~ 0.033uF |
|
1000V |
0.1pF ~ 1000pF |
100pF ~10000pF |
|
2000V |
0.1pF ~ 1000pF |
100pF ~1000pF |
|
1210 |
100V |
100pF ~ 4700pF |
100pF ~ 1uF |
250V |
100pF ~ 4700pF |
100pF ~ 0.22uF |
|
500V |
100pF ~ 2700pF |
100pF ~ 47nF |
|
1000V |
100pF ~ 1000pF |
100pF ~ 15000pF |
|
2000V |
100pF ~ 220pF |
100pF ~ 2200pF |
|
1812 |
100V |
100pF ~ 10000pF |
100pF ~ 1uF |
250V |
100pF ~ 5600pF |
100pF ~ 0.47uF |
|
500V |
100pF ~ 4700pF |
100pF ~ 100nF |
|
1000V |
100pF ~ 2200pF |
100pF ~ 22nF |
|
2000V |
100pF ~ 1000pF |
100pF ~ 4700pF |
|
2220 |
100V |
100pF ~ 10000pF |
100pF ~ 4.7uF |
250V |
100pF ~ 5600pF |
100pF ~ 0.68uF |
|
500V |
100pF ~ 4700pF |
100pF ~ 0.33uF |
|
1000V |
100pF ~ 2200pF |
100pF ~ 0.1uF |
|
2000V |
100pF ~ 1000pF |
100pF ~ 10000pF |
|
Custom design products are available on request, please contact us for more spec details.
