1206 100uH 80mA 15.6 ohm MuRata LQH31CN101K03L SMD Power Inductor
1. Specification
| |
| Brand name | muRata |
| Part No. | LQH31CN101K03L |
| Inductance | 100uH |
| Tolerance | ±10% |
| Inductance test frequency | 1MHZ |
| Rated current (Itemp) (Based on Temperature rise) | 80mA |
| Max. of DC resistance | 15.6 ohm |
| Avg. of DC resistance | 12.0 ohm ±30% |
| Self resonance frequency (min.) | 7MHz |
| Operating temperature range (Self-temperature rise is not included) | -40~85°c |
| Class of magnetic shield | No Magnetic shield |
| Shape | |
| L size | 3.2 ±0.3mm |
| W size | 1.6 ±0.2mm |
| T size | 1.8 ±0.2mm |
| Size code in inch(mm) | 1206 (3216) |
| Reference | |
| Packaging | φ180mm Embossed taping & Reel |
| Pack Quantity | 3000 pcs/reel |
| Category | Inductor |
| Family | power Inductor |
| |
|
2. Application
- For general purpose
- the high-frequency circuits of mobile communications equipment, such as mobile phones, wireless LAN, and others.
3. Feature
- Inductor of the multilayer & non-magnetic core structure.
- high Q (Quality factor) value
- Max. height 0.55 mm
- Reflow soldering applicable
- Complied with RoHS Directives
- Enables a smaller size and lower cost compared to the wire wound structure
- Enabling use in a wide range of applications
4. About Inductor from muRata
- Classification and Structure of Chip Inductor
We also can provide various inductors from TDK, Samsung, Coilcraft, Taiyo, etc..
and most of them were in stock.
Any enquiry please feel free to contact us.
