0402 10nH 300mA 0.35ohm MuRata LQG15HN10NJ02D Ceramic Core Chip Inductors
1. Specification
| |
| Brand name | muRata |
| Part No. | LQG15HN10NJ02D |
| Inductance | 10nH |
| Tolerance | ±5% |
| Inductance test frequency | 100MHZ |
| Rated current (Itemp) (Based on Temperature rise) | 300mA |
| Max. of DC resistance | 0.35Ω |
| Q (min.) | 8 |
| Q test frequency | 100MHZ |
| Self resonance frequency (min.) | 3200MHZ |
| Operating temperature range (Self-temperature rise is not included) | -55~125°c |
| Shape | |
| L size | 1.0 ±0.05mm |
| W size | 0.5 ±0.05mm |
| T size | 0.5 ±0.05mm |
| Size code in inch(mm) | 0402 (1005) |
| Reference | |
| Packaging | φ180mm Paper taping & Reel |
| Pack Quantity | 10000 pcs/reel |
| Category | Inductor |
| Family | RF Inductor |
| |
|
2. Application
- For general purpose
- the high-frequency circuits of mobile communications equipment, such as mobile phones, wireless LAN, and others.
3. Feature
- Inductor of the multilayer & non-magnetic core structure.
- high Q (Quality factor) value
- Max. height 0.55 mm
- Reflow soldering applicable
- Complied with RoHS Directives
- Enables a smaller size and lower cost compared to the wire wound structure
- Enabling use in a wide range of applications
4. About Inductor from muRata
- Classification and Structure of Chip Inductor
We also can provide various inductors from TDK, Samsung, Coilcraft, Taiyo, etc..
and most of them were in stock.
Any enquiry please feel free to contact us.
