Specifications
Combined EMC testing generator1, Meet the EN61000-4-2, EN61000-4-4 EN61000-4-5 testing standards
2,TUV certified
Combined EMC testing interference generator PRM61245A contains ESD, EFT and Lightning surge three functions,it complies with the latest standards EN61000-4-2,EN61000-4-4,EN61000-4-5
Product characteristic:
ESD, EFT, and SURGE, three functions combined into a single, more cost-effective
Built-in international standards level parameters and user models parameters,very convenient
LCD display, Intelligent control,Use the Programmable imported high-voltage power supply, Reliable performance
Built-in intelligent couping/decoupling network. Testing safely
Built-in the RS232 interface ,Remote operated by the optional control software.
Model |
PRM61245A |
||
ESD |
Output voltage |
0.2~± 20 kV ± 5% ( or 30kV)Positive / Negative |
|
Testing functions |
Contact discharge /Air discharge |
||
Working form |
Discharge interval 0.05 ~ 99.99s ,Testing form20PPS discharge;setting less than0.05s,be called single discharge |
||
Discharge capacitor/Resistor |
150pF /330 Ω (optional) |
||
Current rise time |
0.6 ~ 1ns |
||
EFT |
Output voltage |
0 ~± 4500V Positive/Negative//Switchable |
|
Pulse frequency |
1kHz~1200kHz ± 10%, adjustable |
||
Resistor |
50 Ω± 20% |
||
Rise time |
5ns ± 30% |
||
Impulse duration |
50 Ω load |
50ns ± 30% |
|
1k Ω load |
35 ns~150 ns |
||
Number of burst |
1~255 |
||
Burst period |
300mS ( 0.15~9.99 S adjustable,step 0.01S ) |
||
EUT coupling path |
Built-in,single phase three line AC220V,50/60Hz,max 16A |
||
SUG |
Open -circuit t voltage/short-circuit current |
Waveform parameters parameters of Open -circuit t voltage: 1.2/50 μ s , 0.2~ 6kV |
|
Surge polarity |
Positive / Negative/Switchable |
||
Phase |
Synchronism 0 °~ 360 °selectable/Asynchronism |
||
Output impedance |
Complex impedance: 2 Ω |
||
Coupling path |
Built-in,single phase three line AC220V,50/60Hz,max 16A |
||
Surge count |
1~9999 |
||
Surge interval |
10~9999s |
||
Working power supply |
AC220V 50/60Hz |
||
