Home > Metallurgy, Mineral & Energy > Solar & Renewable Energy > Solar Cell > Mono-crystalline Solar Panels Wholesale Price From REOO

Mono-crystalline Solar Panels Wholesale Price From REOO

Mono-crystalline Solar Panels Wholesale Price From REOO thumbnail-1
Mono-crystalline Solar Panels Wholesale Price From REOO thumbnail-2
Mono-crystalline Solar Panels Wholesale Price From REOO thumbnail-3
Mono-crystalline Solar Panels Wholesale Price From REOO thumbnail-4
Mono-crystalline Solar Panels Wholesale Price From REOO thumbnail-5
Mono-crystalline Solar Panels Wholesale Price From REOO thumbnail-6
Mono-crystalline Solar Panels Wholesale Price From REOO photo-1
Mono-crystalline Solar Panels Wholesale Price From REOO photo-2
Mono-crystalline Solar Panels Wholesale Price From REOO photo-3
Mono-crystalline Solar Panels Wholesale Price From REOO photo-4
Mono-crystalline Solar Panels Wholesale Price From REOO photo-5
Mono-crystalline Solar Panels Wholesale Price From REOO photo-6
US$ 0.5 - 1.8 MOQ: 100 Watts
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
REOO
Model Number:
RO 040
Contact Supplier Request Quote Chat Now
Nantong Reoo Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name REOO
Model Number RO 040
Material Monocrystalline Silicon
Size 634*534*35mm
Number of Cells 60pcs
Max. Power 38W~43w

Mono-crystalline solar panels wholesale price from REOO

                                 Temperature Coefficients

NOCT                                                                  45+/-2  oC

Voltage temperature coefficient(Voc)                     -0.36%/  oC

Current temperature coefficient(Isc)                      +0.033%/ oC

Power temperature coefficient(Pmpp)                     -0.44%/  oC

Minimum power tolerance                                      +/-10%oC

 NOCT:  Nominal Operating Cell Temperature

  Mono-crystalline solar panels wholesale price from REOO

Mechanical Data

Solar Cell

Mono-crystalline 156×156mm

 Frame

Anodized  aluminium

 Weight

4kg

Dimension

634×534×35mm

Mono-crystalline solar panels wholesale price from REOO

                         Warranty and certifications

  Warranty              3 years workmanship,10 years90%,25 years 80% power warranty

   Certifications       TUV , CE



                                 Electrical Data

Module Type

RO 043-12

RO 040-12

RO 038-12

Nominal peak power(Wp)

43W

40W

38W

Nominal voltage(Vmp)

17.2V

17.2V

17.2V

Nominal current(Imp)

2.50A

2.33A

2.20A

Open circuit voltage(Voc)

21.6V

21.6V

21.6V

Short circuit current(Isc)

2.84A

2.65A

2.51A

Module efficiency

12.7%

11.9%

11.3%

Operating Temperature

-40 to +85oC

-40 to +85oC

-40 to +85 oC

Maximum System Voltage

1000V DC

1000V DC

1000V DC

  STC:1000W/m²,25

Mono-crystalline solar panels wholesale price from REOO



 Product Features:

1  Designed according to and complying with all requirements in IEC 61730 and IEC 61215 ed2(certified by TUV Rheninland);

2  White tempered glass,EVA ,weather proof substrate fim and anodized aluminium frame provide adequate protection against various environmental conditions

3  All backed by a 25 year limited power warranty(more than 80%)and 2 year workmanship warranty

4   Customization on request

5   Cells are 100% visual inspected and sorted according to electric characters against mismatching

6  Visual inspection,performance measurement and dielectric strength tests on every product

7   The junction box and connectors with IP 65 protection degree provide convenient reliable electric connection;The incorporated schottky bypass diodes protect the module from hot spot damages

Company Information

Mono-crystalline solar panels wholesale price from REOO



Why buy solar panel production line from REOO technology ?

We have more experience for design, manufacturing, packing, shipping, installation, training, trial production in all of world.

We have more than 10 years experience for manufacture and export solar panel machines

Our engineer can install all of machines for making solar panel.

Our engineer can supply best technology.

We can train for all of machines.

We supply all tools and accessories for production, It is difficult be purchased in other countries. and these tools is free, Do not need money.

We can supply all of raw material for manufacture solar panel in good quality and lower price.

Please look the video from by REOO solar.

We can supply technical documents for apply TUV certificated. It is free.
