Home > Products > Solar Panel > High efficiency 200W Poly solar panels for solar system Quality Choice
High efficiency 200W Poly solar panels for solar system Quality Choice
- 30000 Piece / Pieces per Month
- Shanghai
- T/T
-
12V Portable Mini Air Pump
-
DC 12V Portable Heavy Duty Plastic Shell Air Compressor with Light
Quality Choice
-
Electric Portable Heavy Duty Plastic Shell Air Compressor -30mm 2 Cylinder
-
12V Heavy Duty Plastic Shell Air Compressor with Light
-
12V Mini Heavy Duty Plastic Shell Air Compressor Price
-
12V Heavy Duty Car Air Compressor /Tire Inflators with light - 30mm Cylinder
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | REOO | Model Number: | RO200-24 |
| Material: | Polycrystalline Silicon | Size: | 1547mm*983mm*35mm | Number of Cells: | 72(6X12) |
| Max. Power: | 200W |
Product Description
Class A 200W Poly solar panel
Solar panel power from 3W to 300W according to customer's requirements.
Solar panel nominal 12/24V DC for standard output.
Aesthetic appearance and rugged design to withstand high wind pressure, hail, snow load.
Rigorous quality control to meeting the highest international standard.
Solar panel encapsulated with high transmission low-iron, tempered glass.
Cells are laminated with TPT and EVA ensuring longer life and maximum performance.
TPT imported from Krempel, Germany, ensure 25 years output power more than 80% .
Electrical Characteristics:
Electrical Characteristics RO200-24
Electrical Characteristics | BCT200-24 |
Maximum power at STC(Pmax) | 200W |
Optimum operating voltage(Vmp) | 34.4V |
Optimum operating current(Imp) | 5.81A |
Open-circuit voltage(Voc) | 43.2V |
Short-circuit current(Isc) | 6.5A |
Short-circuit current temperature coefficient | (0.065±0.015)%/ °C |
Open-circuit voltage temperature coefficient | -(80±10)MV/°C |
Peak power temperature coefficient | -(0.5±0.05)%/ °C |
NOCT(Air 20°C;Sun 0.8kw/m wind 1m/s) | 47±2°C |
Operating temperature | -40°C TO 85°C |
Maximum system voltage | 600V DC |
Power tolerance | ±3% |
Features:
- Nominal 12V DC standard output
- high efficiency
- Outstanding low-light performance
- High transmission tempered glass
- Rugged design to withstand high wind pressure and snow load, easy installation
- Aesthetic appearance
- Design to met with unique demand of customer
- 25 years output warranty
Materials:
- Solar cell ------conversion efficency of solar cells:24%-17%.
- Front glass-----3.2mm,high transmission. Low iron. Tempered glass
- EVA------------excellent anti-aging reistance.
- TPT-------------TPT hot seal made of flame resistance.
- Flame ----------reinfored anodixed aluminum flame
- Junction box---Ip 54 rated and lp65 rated,high quality. With diode protection.
Installation
We send engineer or technicians to buyers factory to install machine.
All expenditure on travel, food, accommodation and transportation of our engineers/ technicians for installation will be borne by buyer.
REOO company borne the salary of engineer.
Training
We supply both overseas and local training to the engineers and technicians on operation and maintenance.
buyer borne air tickets, lodging, food and training material .
Minimum 12 (twelve) months warranty of all products and services .
guarantee for the spares and required maintenance or replacement support are to be provided . Buyer borne the cost of the material for parts of maintenance.
Backup spares:
We supply essential backup spares. items beyond warranty periods, buyer borne the cost.
Why buy solar panel production line from REOO technology ?
We have more experience for design, manufacturing, packing, shipping, installation, training, trial production in all of world.
We have more than 10 years experience for manufacture and export solar panel machines
Our engineer can install all of machines for making solar panel.
Our engineer can supply best technology.
We can train for all of machines.
We supply all tools and accessories for production, It is difficult be purchased in other countries. and these tools is free, Do not need money.
We can supply all of raw material for manufacture solar panel in good quality and lower price.
Please look the video from by REOO solar.
We can supply technical documents for apply TUV certificated. It is free.
