Help CenterMC4 P Solar Panel Cable Connector Male Female Electrical Waterproof
Related Products
-
Fast Connecting With Tools PV Solar Power pv MC3 ConnectorUS$ 0.5 - 1MOQ: 100 Pairs -
MC4 T Type Wire Connector Crimping MC4 ConnectorsUS$ 2.8 - 4.3MOQ: 100 Pairs
-
REOO MC4 Connector Assembly Y Branch MC4 Connector for Solar CableUS$ 3.3 - 4MOQ: 100 Pairs
-
REOO 30A Male Female MC4 PV Wire Solar Cable ConnectorUS$ 0.7 - 0.8MOQ: 100 Pairs
-
MC4 Connector TUV Waterproof IP67 for Solar Panel Cable T Branch ConnectorUS$ 2.8 - 4.3MOQ: 100 Pairs
Solar power cable connector
MC4 Solar power connector
Raw material |
Used for |
Price |
Characteristic |
|
PPO PX9406P-7001 |
Junction box |
Lower |
Most of company use it for junction box. |
|
PPO 540Z |
Junction box |
Lower |
Lower price |
|
PPO V0150B |
Junction box |
Middle |
RTI higher than PX9406P |
|
PPO 644Z |
Junction box |
Middle |
Good quality for junction box |
|
PA66 FR7025 |
Connector nut |
Middle |
Most of company use it for connector |
|
PA66 FR370 |
Connector nut |
Middle |
Most of company use it for connector |
|
PC EXL9330 |
Connector house |
Expensive |
Top quality. |
Insulation material |
PPO |
Rated current |
30A |
Rated voltage |
1500V |
Test voltage |
6KV(50Hz,1Min) |
Contact material |
Copper, tin plated |
Contact resistance |
5mΩ |
Degree of protection |
IP67 |
Safety class |
Ⅱ |
Flame calss |
UL94-V0 |
Insertion force |
≤50N |
Withdrawal force |
≥50N |
A temperature range |
-40℃ ~ + 90℃ |
Connector diameter |
2.5mm2,4 mm2, |
Suitable cable: |
AWG14 / 12 / 10 |
MC4 RO-1P |
1000 pairs in a carton. |
Measure |
38cm*29cm*47cm |
Net weight |
22 kg / carton |
Gross weight |
22.9 kg / carton |
