Home > Electrical & Electronics > Electric Motor > DC Motor > Massager Motor RS-555PHV, 24VDC Motor, Commercial Massager Motor

Massager Motor RS-555PHV, 24VDC Motor, Commercial Massager Motor

Massager Motor RS-555PHV, 24VDC Motor, Commercial Massager Motor thumbnail-1
Massager Motor RS-555PHV, 24VDC Motor, Commercial Massager Motor photo-1
US$ 1.15 - 3.5 MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
dong hui
Model Number:
RS-555PHV, 24VDC motor, commercial massager motor
Contact Supplier Request Quote Chat Now
Shenzhen Xin Dong Hui Motor Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shen zhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name dong hui
Model Number RS-555PHV, 24VDC motor, commercial massager motor
Usage Fan, Home Appliance, Other, Fan, Home Appliance, RS-555PHV, 24VDC motor, commercial massager motor
Certification ROHS
Type Micro Motor
Torque 35.86mN.m
Construction Permanent Magnet
Commutation Brush
Protect Feature Other, RS-555PHV, 24VDC motor, commercial massager motor
Speed(RPM) 24000rpm no load
Continuous Current(A) 1.4A no load
Output Power 78.1W
Voltage(V) 12V
Efficiency IE 1

Specifications

RS-555PHV, 24VDC motor, commercial massager motor
High rpm speed
Dia.*L:35.8mm*57mm

Specifications:

RS-555PHV, 24VDC motor, commercial massager motor

High rpm speed
Dia.*L:35.8mm*57mm
Weight:200g Approx



The models we list below are part of our existing designs. We offer specific motor design for every customer.Massager motor RS-555PHV, 24VDC motor, commercial massager motor



Motor photo:

Massager motor RS-555PHV, 24VDC motor, commercial massager motor



Production  flow:

Massager motor RS-555PHV, 24VDC motor, commercial massager motor

Massager motor RS-555PHV, 24VDC motor, commercial massager motor



Massager motor RS-555PHV, 24VDC motor, commercial massager motor




       Since Dong Hui Motor established in 2003, has been committed to the development and production of micro motor, including 4 major product series: Micro DC motor, DC gear motor, coreless motor, brushless motor. All products are widely used in consumer electronics, electric toys, household appliances, home appliance,office automation equipment, medical equipment, power tools, automotive and other fields. Learn More About us:

1. Our main products: Dia4~100mm DC Micro Motor and Gear Motor

Auto dc motor, Electric motor,Brushless motor, Gear Motor, DC Motor, Brush DC motor, Spur Gear motor, Micro Motor, Vibration motor etc.

2. Products size range: Diameter: 4-100mm

3. DC Voltage range: 1.5V -42V

  AC rectify: 100V, 110V, 220V, 230V, 240V etc.

4. Speed range: 1 RPM-30,000RPM

5. Stall torque: 5g.cm-30kg.cm

6. Application: Home appliance, Power Tools, Toys & Model, Precision Instrument, Office equipment, Personal care product, Automotive, Audio& Visual equipment etc.
