12v 24v Low RPM dc Gear Motors With 16mm Geared Box

FOB Price

US$ 5 - 10 / Piece

500 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Brand Name	DH Motor
Model Number	DGA-050	Usage	Boat, Car, Electric Bicycle, Fan
Certification	CCC, CE, ROHS, UL	Type	Gear Motor
Torque	Requests	Construction	Permanent Magnet
Commutation	Brush	Protect Feature	Totally Enclosed
Speed(RPM)	Variable Speed	Continuous Current(A)	Current
Output Power	TBD	Voltage(V)	24V
Efficiency	IE 1

12v Low RPM 16mm Geared DC Motor 24v dc gear motors

Specification:

This Gear motor is assembled by DRF-050 DC Motor and 16mm Gear Box.

F-050 DC Motor Specification

1. Rated Voltage:DC 3-24V

2. 14000 RPM Max NO Load.

3. Precious Metal Brush Motors
4.Diameter 15.5mm,length 26.9mm,shaft 2.5mm
5.Weight: 20g Approx

16mm Gear Box Specification

1. Reduction Ration: From 1/4 to 1/2418. Please let us know your need, we can customize for your any request.

2. Shaft Diameter: 3mm (Don't worried if Not your need, It can be customized )

3. Can be equipped with encoder

4. Weight: 10g Approx

Dimensions and Parameters

Notice: Our Comany Can customized for your request, Please contact us to know more details.
