Stainless Steel Lab Vacuum Glove Box price
EQ-VGB-1 is a small size stainless steel glove box with Airlock Chamber, Gauges and vacuum Flanges,
which allow glove box operate under vacuum to remove moisture and oxygen without expensive inert gas purging,
It is an ideal tool for material and chemical researchers to process air sensitive materials and solutions.
Specification of the vacuum glove box.
Glove Box Chamber | Case Material: Made of 11 gauge (3mm thickness) 304 stainless steel sheet with sport frame, which provide heavy duty structure for vacuum Dimensions: 555mm(L) x 444mm(W) x 414mm(H) Max. Positive Pressure: 810 Torr (1.1 atm) Note: Gloves cannot work if pressure is higher than 810 Torr Max. Vacuum Level: 0.5 Torr Note: Stainless Steel case may deform at higher vacuum level |
Air-lock Chamber | Dimensions: 200mm(ID) x 270mm(L) Max. Vacuum Level: 0.05 Torr |
Vacuum gauge and valves | Two vacuum flanges are included for glove box to achieve vacuum to remove moisture and oxygen without expensive inert gas purging Do not operate under vacuum status. Vacuum process is used for purging the glove box chamber before operation. One KF-25 connector is installed in the back for connecting humidity monitor or other testing equipment |
Leakage Rate in Glove Box Chamber | < 6 Torr/hour |
Power Extension | One extension socket (Max power 1500W) is installed in the glove box main chamber.
Note: 110V power cord was included for immediate use. |
Gloves | One pair of Latex Gloves are included for immediate use Optional: You may order 6'' Butady gloves here because they have: Increased stretching, bending ability and tear strength High effectiveness when vaporized hydrogen peroxide (VHP) is present High resistance to aromatics, hydrocarbons, solvents, fats, and acids Resistozone High static dissipative qualities |
Vacuum pump and fittings (Optional) | Vacuum pump and fittings are not included. (Please order separately under Personalization) |
Product Dimensions | 1186mm(L) x 480mm(W) x 490mm(H) |
Warranty | One year limited warranty with lifetime support |
Detailed picture of the vacuum glove box:
Plywood case
Payment: T/T , L/C , Paypal, etc.
Delivery: within 2 weeks
