Wheat reaper binder machine 4LZ-1.2

FOB Price

USD $7,500 - $8,000 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Shenzhen
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Application:	Farm Machinery	Type:	Combine Harvester
Drive Type:	Gear Drive	Usage:	Grain Harvester	Place of Origin:	Zhejiang, China
Brand Name:	WISHOPE	Model Number:	4LZ-1.2	Dimension(LWH):	420016502010
Weight:	2000kg	Certificate:	CE	Warranty:	12 month
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

Wheat reaper binder machine 4LZ-1.2

This wheat reaper binder machine is specially for moutain area and small field. The machine is easy for operation, and maintenance, it is a safety and energy-saving machine.

Specification:
Overall Dimension(LWH)	4200×1650×2010
Weight (kg)	2000
Feeding Capacity( kg/s )	1.2
Harvesting Capacity(hm²/h):	0.1-0.3
Engine	Engine Model: QC2110
	Rated Power ( kw/hp ): 32/43
	Engine Type: Water-Cooled, 2-Cylinder, DI-Injection, Vertical Diesel.
	Rated Rotation Speed (r/min) : 2600
	Fuel Tank Capacity ( l ): 25
Driving System	Rubber Track(mm): 350 x 90 x 42 / 400 x 90 x 42
	Crawler Steering Radius ( mm ): left turn 2300; right turn 2300
	Minimum Ground Clearance (mm): 250
	Type of Gearbox: Mechanism + HST(3F, 3R)
	Theoretical Operating Speed ( km/h ): 0~4
	Type of Brake: By Foot.
	Steering: Clutch and Brake.
Cutting header	Pickup Reel: Type: Eccentric Tooth ( off-centre ); Diameter( mm ): 900; Nos: 5
	Height Adjustment: Hydaulics.
	Cutting Bar Length ( mm ): 1400
	Type of Header Auger: Telescopic Screw Conveying.
	Type of Blade: V Type / Left and Right.
	Rape Seed Extension: Optional
Threshing & Separating & Cleaning System	Threshing System: Spiked Tooth Axial Flow
	Threshing Cylinder Size Diameter × Length ( mm ): 550×1070
	Reshresher: Blade-Rotation
	Vibrating Sieve: Adjustable Seive / Meshing Seive ( optional )
	Blower Fan: Type: Swirl; Diameter( mm ): 260; Nos: 2
Grain Storing	Manual Operation.

Details of wheat reaper binder machine

Working show

Factory & warehouse

More details about us
