Auto Spring Return Potentiometer Camera Control Joystick

Name: Auto Spring Return Potentiometer Camera Control Joystick
Brand: TENLEE
SKU: 112031175
Availability: InStock

Yueqing Tenlee Electric Co., Ltd.

US$ 7 - 15 MOQ: 10 Pieces

Key Specifications

Brand Name:

TENLEE

Model Number:

TL300,400 series

Type:

Joystick

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo/shanghai

Delivery Detail:

Delivery time depends on order quantity.

Brand Name TENLEE

Model Number TL300,400 series

Type Joystick

Place of Origin Zhejiang, China

Specifications

1.industrial
2.2 axis,3 axis,4d available
3.switch,button type available
4.long life,small resetting error

1.Features

Flexible operation

Small resetting error

Long life

2.Typical applications

CCTV control system and movable camera

Testing and measurement equipment

Medical imaging system

Automated machine control

Video editting and manufacturing equipment

Industrial and scientific instruments

3.Specifications

Description	3-axis auto spring return potentiometer joystick
Main performance	TL300A/B	TL301	TL400A	TL400B
Switch push button on the top of the handle	without	without	with	with
Resistance	5KΩ,10 KΩ	5KΩ,10 KΩ	5KΩ,10 KΩ	5KΩ,10 KΩ
Resistance tolerance	±5%	±5%	±5%	±5%
Independent linearity tolerance	±1%	±1%	±1%	±1%
Resolution	Infinity	Infinity	Infinity	Infinity
Temperature coefficient	±400ppm/°C
Output smooth	MAX 0.5%
X and Y axis Rotational Angle	±25°-- 30°
Z axis rotational angle	±45°
TL300 Z axis potentiometer TL400 Z axis potentiometer and the wire of knob	AWG28 Teflon insulation silver-plating colored wire. Standard line 100mm or according to customer request
Insulation resistance	50MΩ@500VDC,60sec
Operation torque	X and Y axis 440gf, Z axis 880gf
Reposition error rate	±1%	±1%	±1%	±1%
Rotational life expectancy	500,000 times
Operating temperature	-10°C~80°C
Instruction for modal choosing M1: the potentiometer is 5K Ohm, MAX from 1.8KΩ±5% to 3.2KΩ±5%,220° M2: the potentiometer is 5K ohm, MAX from 0 to 5K ohm, 50° M3: the potentiometer is 10K ohm, MAX from 6.5KΩ±5% to 3.5 KΩ±5%,220° M4: the potentiometer is 10K ohm, MAX from 0 KΩ±5% to 10 KΩ±5%,50°
