Single Axis IEPE PE Piezoelectric Quartz Accelerometer

Yueqing Tenlee Electric Co., Ltd.
Single Axis IEPE PE Piezoelectric Quartz Accelerometer thumbnail-1
Single Axis IEPE PE Piezoelectric Quartz Accelerometer photo-1
US$ 110 - 140 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
TENLEE
Model Number:
TL122A,121A,221A,222A
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name TENLEE
Model Number TL122A,121A,221A,222A
Usage Vibration Sensor
Theory Other, piezoelectric
Output Other, voltage,charge

Specifications

1.vibration/product/structure/package drop test,vibration control
2.high rigidity,quick response,large G value
3.IEPE,PE

1.General Purpose Piezoelectric Accelerometers

Piezoelectric accelerometers offer tremendous versatility for shock and vibration measurements. These rugged sensors can withstand adverse environmental conditions. A wide variety of configurations are available to support multiple application requirements. Specialty units are also available through mechanical or electrical design adjustments or additional qualification testing.

There are two broad categories for piezoelectric accelerometers-those that contain built-in signal conditioning electronics (IEPE type) and those that do not (Charge Output(PE) type). Generally, IEPE accelerometers are preferred, due to ease of use and lower system cost. Charge Output accelerometers are used for high temperature environments, which would otherwise destroy the electrical components contained in an IEPE type.



2.Applications

Routine Vibration Testing; Product Testing; Structural Testing; Vibration Control; Package Drop Testing



3.Specifications

Model

Sensitivity

Frequency Range (±10%)

Measuring Range

Resolution

Operating Temperature

Weight

Output Type

Mounting Type

Size

121A01

1mV/g

1Hz to 12kHz

±5000g

10mgrms

-40 to +121°C

9Gram

Top M5

M5

Φ12×20mm

122A01

1mV/g

1Hz to 12kHz

±5000g

10mgrms

-40 to +121°C

10Gram

Side M5

M5

Φ12×16mm

121A05

5mV/g

1Hz to 12kHz

±1000g

5mgrms

-40 to +121°C

9Gram

Top M5

M5

Φ12×20mm

122A05

5mV/g

1Hz to 12kHz

±1000g

5mgrms

-40 to +121°C

10Gram

Side M5

M5

Φ12×16mm

121A10

10mV/g

1Hz to 10kHz

±500g

2.5mgrms

-40 to +121°C

9.5Gram

Top M5

M5

Φ12×20mm

122A10

10mV/g

1Hz to 10kHz

±500g

2.5mgrms

-40 to +121°C

12Gram

Side M5

M5

Φ12×16mm

121A20

20mV/g

1Hz to 10kHz

±250g

1.5mgrms

-40 to +121°C

9.5Gram

Top M5

M5

Φ12×20mm

122A20

20mV/g

1Hz to 10kHz

±250g

1.5mgrms

-40 to +121°C

12Gram

Side M5

M5

Φ12×16mm

121A50

50mV/g

0.5Hz to 8kHz

±100g

1mgrms

-40 to +121°C

18Gram

Top M5

M5

Φ13×20mm

122A50

50mV/g

0.5Hz to 8kHz

±100g

1mgrms

-40 to +121°C

18Gram

Side M5

M5

Φ13×16mm

121A100

100mV/g

0.5Hz to 8kHz

±50g

0.5mgrms

-40 to +121°C

18Gram

Top M5

M5

Φ13×22mm

122A100

100mV/g

0.5Hz to 8kHz

±50g

0.5mgrms

-40 to +121°C

20Gram

Side M5

M5

Φ13×22mm

121A200

200mV/g

0.3Hz to 5kHz

±25g

0.2mgrms

-40 to +121°C

28Gram

Top M5

M5

Φ18×31mm

122A200

200mV/g

0.3Hz to 5kHz

±25g

0.2mgrms

-40 to +121°C

30Gram

Side M5

M5

Φ18×26mm

121A500

500mV/g

0.2Hz to 3kHz

±10g

0.1mgrms

-40 to +121°C

40Gram

Top M5

M5

Φ18×31mm

122A500

500mV/g

0.2Hz to 3kHz

±10g

0.1mgrms

-40 to +121°C

57Gram

Side M5

M5

Φ18×26mm

122A1000

1000mV/g

0.2Hz to 1kHz

±5g

0.05mgrms

-40 to +121°C

65Gram

Side M5

M5

Φ26x30 mm



Model :

Sensitivity

Frequency Range (±10%)

Measuring Range

Operating Temperature

Output Type

Mounting Type

Size

Weight

221A10

10pC/g

1Hz to 12kHz

±5000g

-54 to +150°C

M5

Top M5

Φ13x25mm

12Gram

222A10

10pC/g

1Hz to 12kHz

±5000g

-54 to +150°C

M5

Side M5

Φ13x20 mm

12Gram

221A25

25pC/g

1Hz to 10kHz

±2000g

-54 to +150°C

M5

Top M5

Φ13x25mm

15Gram

222A25

25pC/g

1Hz to 10kHz

±2000g

-54 to +150°C

M5

Side M5

Φ13x20 mm

15Gram

221A50

50pC/g

0.5Hz to 6kHz

±1000g

-54 to +150°C

M5

Top M5

Φ16x28 mm

32Gram

222A50

50pC/g

0.5Hz to 6kHz

±1000g

-54 to +150°C

M5

Side M5

Φ16x23 mm

32Gram

221A100

100pC/g

0.5Hz to 6kHz

±1000g

-54 to +150°C

M5

Top M5

Φ16x28 mm

38Gram

222A100

100pC/g

0.5Hz to 6kHz

±1000g

-54 to +150°C

M5

Side M5

Φ16x23mm

38Gram

221A200

200pC/g

0.5Hz to 5kHz

±600g

-54 to +150°C

M5

Top M5

Φ18x31 mm

45Gram

222A200

200pC/g

0.5Hz to 5kHz

±600g

-54 to +150°C

M5

Side M5

Φ18x26 mm

45Gram

221A500

500pC/g

0.2Hz to 3kHz

±150g

-54 to +150°C

M5

Top M5

Φ18x31 mm

50Gram

222A500

500pC/g

0.2Hz to 3kHz

±150g

-54 to +150°C

M5

Side M5

Φ18x26 mm

50Gram

222A1000

1000pC/g

0.2Hz to 2kHz

±80g

-54 to +150°C

M5

Top M5

Φ28x26 mm

60Gram

2106C

25pC/g

1Hz to 10kHz

±2000g

-54 to +150°C

M5

Side M5

Φ13x20 mm

15Gram



4.Models

single axis IEPE PE piezoelectric quartz accelerometersingle axis IEPE PE piezoelectric quartz accelerometer





5. Packaging

single axis IEPE PE piezoelectric quartz accelerometer





6. Shipping

Each product is tested before shipping.

We can help arrange express shipping, sea/air shipping.

single axis IEPE PE piezoelectric quartz accelerometer
