Help CenterThe Galvanized Steel YDF Induced Fan
Related Products
-
Fire Smoke Double Gear Ventilation Axial FanUS$ 50 - 200MOQ: 10 Pieces -
HTFC Ventilation Centrifugal Single Gear BlowerUS$ 200 - 500MOQ: 1 Set
-
Ventilation Exhaust Fans for HVAC SystemsUS$ 200 - 2,000MOQ: 10 Pieces
-
Durable Electric Fans & Blowers With New DesignUS$ 200 - 500MOQ: 30 Sets
-
4 Centrifugal Pressure Fans Explosion ProofUS$ 200 - 500MOQ: 10 Sets
Fire Smoke Double Gear Ventilation Axial Fan
Product Profile:
Fire Smoke Double Gear Ventilation Axial Fan assembled with high-temperature resistance motor and motor cooling system. Compared with HTFC centrifugal blower, it is affordable and suitable for the places where do not demand low noise and special outlet angle.
Products advantages: Our company was founded in 2005, the annual output value is nearly one hundred million RMB now. Using pipelined professional mold production methods, so we can meet the production needs of large orders and guarantee our products are reliable quality. Complete accessories production and distribution make it easier to install.
Good quality control processes, all products have been through four inspection process. The balance precision of impellers is less than G5.6.Wind speed, electric current, voltage and noise control all achieve CNS.
Structure:
(1) Wheel hubs and blades are molded by hydraulic tensioning
(2) Full welding connection
(3) Flanges of the cylinder are made of spinning flanging process.
Features:
(1) High qualitycarbon steel, Cost-effective
(2) Customized paint color
(3) 100 degrees (Can run 20 hours continuously), 300 degrees (Can run 60 minutes continuously)
(4) Dual frequency motor
Application:
This series of products are widely used in high-rise building, industrial and mining enterprises, underground garage and warehousing workplace ventilation.
Standard: impeller:chassis (cylinder, guide vanes, the inner cylinder, motor bracket); motor; chassis; cooling duct
Optional Accessories: damping device; control box; grille; mating flange;muffler
Performance Table
Device Number |
Rotating Speed(r/min) |
Air Volume(m³/h) |
Total Pressure(Pa) |
Motor Model |
Power(kw) |
Weight(kg) |
8 |
1450 |
31421 |
600 |
YDT160M-4/6 |
8/2.8 |
230 |
30364 |
635 |
|||||
29172 |
661 |
|||||
28598 |
692 |
|||||
26012 |
723 |
|||||
960 |
20800 |
263 |
||||
20103 |
278 |
|||||
19314 |
290 |
|||||
18934 |
303 |
|||||
17222 |
317 |
|||||
10 |
1450 |
45679 |
630 |
YDT160L-4/6 |
12/4 |
305 |
42960 |
665 |
|||||
40000 |
690 |
|||||
38200 |
736 |
|||||
35000 |
770 |
|||||
960 |
30255 |
276 |
||||
28442 |
291 |
|||||
26483 |
302 |
|||||
25291 |
322 |
|||||
24019 |
338 |
The above table is just part of the performance of our product. We can provide customized product, so please make your performance requirements.
