New Sale 2014 Spraying Etching Machine
Negotiable
/ Set
1 Set(Min.Order)
- 40 Set / Sets per Month
- SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Zhejiang, China | |
| Brand Name | MicWell | Model Number | Etching Machine | |
| Rated Power | 2 KW~4KW | Main Axle Rotational Speed | 600 rpm | |
| Dimensions | 250 x 350mm~500 x 750mm |
Product Description
Specifications
Safety DesignPowderless Etching Machine
Good Quality and Favorable Price
Etching Machine For Zinc Copper And Magnesium.
New Sale 2014 Spraying Etching Machine
Overview:
Powderless etching machine,Zinc plate etching machine,hot stamping plates etching machine.
The Cordoba etching machine come in various model from 20 L up to 80 L, the etching machine is a result of 20 years of experience in building powder less etching machines, plus extensive research and development in conjunction with a leading process engraver.
Feature:
This machine can be used to etch both Zinc and Magnesium plates up to a maximum size of 50 x 75cm
[ 20" x 30" ] . Strong construction and corrosion resistant material assure long life of machines.
Plate Rotary motion eliminates the possibility of non-uniform etching with "S" shaped paddles. A highly sensitive temperature controller minimizes temperature variants which take place during the etching cycle. Automatic built in heating and cooling unit works in conjunction with a refrigeration unit.
Usage:
Applications of Zinc or Magnesium plates.
1.Foil stamping.
2.Leather embossing.
3.Thermal Die cutting.
4.Flexography.
5.Label Production.
2.Leather embossing.
3.Thermal Die cutting.
4.Flexography.
5.Label Production.
Specification:
| MODEL | Bath Capacity | Paddle Speed | Maximum Size | Total Power | Power Supply |
| CDETCH20 | 20L | 600 rpm | 250 x 350mm | 2 KW | 220V |
| CDETCH40 | 40L | 600 rpm | 360 x 500mm | 3.3 KW | 220V |
| CDETCH60 | 60L | 600 rpm | 500 x 600mm | 3.5 KW | 220V |
| CDETCH80 | 80L | 600 rpm | 500 x 750mm | 4 KW | 220V |
We Provide You With Sincerely Service, if you have interest,contact us NOW!!!
Mobile Phone:0086-13587958695
TEL: 0086-577-86665723
Fax: 0086-577-86665726
Website: http://micwell-machine.en.china.cn/
