2014 Hot Selling Electric Etching Machine

Name: 2014 Hot Selling Electric Etching Machine
Brand: MicWell
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 40 Set / Sets per Month
Port SHANGHAI
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Place of Origin:	Zhejiang, China	Brand Name:	MicWell
Model Number:	Etching Machine	Rated Power:	2 KW~4KW	Main Axle Rotational Speed:	600 rpm
Dimensions:	250 x 350mm~500 x 750mm

Product Description

Specifications

Safety Design
Powderless Etching Machine
Good Quality and Favorable Price
Etching Machine For Zinc Copper And Magnesium.

2014 Hot Selling Electric Etching Machine

Overview:

Powderless etching machine,Zinc plate etching machine,hot stamping plates etching machine.

The Cordoba etching machine come in various model from 20 L up to 80 L, the etching machine is a result of 20 years of experience in building powder less etching machines, plus extensive research and development in conjunction with a leading process engraver.

Feature:

This machine can be used to etch both Zinc and Magnesium plates up to a maximum size of 50 x 75cm

[ 20" x 30" ] . Strong construction and corrosion resistant material assure long life of machines.

Plate Rotary motion eliminates the possibility of non-uniform etching with "S" shaped paddles. A highly sensitive temperature controller minimizes temperature variants which take place during the etching cycle. Automatic built in heating and cooling unit works in conjunction with a refrigeration unit.

Usage:

Applications of Zinc or Magnesium plates.

1.Foil stamping.
2.Leather embossing.
3.Thermal Die cutting.
4.Flexography.
5.Label Production.

Specification:

MODEL	Bath Capacity	Paddle Speed	Maximum Size	Total Power	Power Supply
CDETCH20	20L	600 rpm	250 x 350mm	2 KW	220V
CDETCH40	40L	600 rpm	360 x 500mm	3.3 KW	220V
CDETCH60	60L	600 rpm	500 x 600mm	3.5 KW	220V
CDETCH80	80L	600 rpm	500 x 750mm	4 KW	220V

We Provide You With Sincerely Service, if you have interest,contact us NOW!!!
