Home > Manufacturing & Processing Machinery > Mixing Equipment > Mixing Tank > High Pressure Glass Reactor (supreme Quality, GG17 or GG3.3 Glass ,321 SS Material,PTFE Sealing) Quality Choice

High Pressure Glass Reactor (supreme Quality, GG17 or GG3.3 Glass ,321 SS Material,PTFE Sealing) Quality Choice

Name: High Pressure Glass Reactor (supreme Quality, GG17 or GG3.3 Glass ,321 SS Material,PTFE Sealing) Quality Choice
Brand: TOPTION
SKU: 112017569
Availability: InStock

High Pressure Glass Reactor (supreme Quality, GG17 or GG3.3 Glass ,321 SS Material,PTFE Sealing) Quality Choice thumbnail-1

High Pressure Glass Reactor (supreme Quality, GG17 or GG3.3 Glass ,321 SS Material,PTFE Sealing) Quality Choice photo-1

US$ 4,500 - 6,500 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

Liquid

Additional Capabilities:

Other

Contact Supplier Request Quote Chat Now

Xian Toption Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai tianjin shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Liquid

Additional Capabilities Other

Place of Origin Shanxi, China

Brand Name TOPTION

Model Number GSH-0.3L High Pressure Reactor

Max. Loading Capacity 300ml(customized)

Voltage 110v/220v

Power(W) 1kw

Certification ISO9001:2008

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

High Pressure Laboratory Reactor 1L
Autoclave
Material:SUS304, SUS316L,Titanum
High temperature and pressure reaction kettle
Stirring Speed

High Pressure Laboratory Reactor

The characteristics of High Pressure Laboratory Reactor 1L

1.Heating type:Electric heating, water recycling, thermal oil, steam, far infrared heating.

2.Charging type:Charging from above, charging from below.

3.Shaft:Adopt self-lubricating wear-resistant sleeve, suitable for mixing various media.

4.Stirring type:Paddle type or anchor type

5.Seal type:Magnetic seal, mechanical seal, packing seal.

Motor:General DC motor, DC servomotor or explosion-proof motor according to the customers’ requirements.

6.Main material:Kettle material is mainly used 0Cr18Ni9(304), 00Cr17Ni14Mo2(316L), 1Cr18Ni9Ti(321). And reactor can be produced by can be produced titanium (TA2), nickel material, tantalum material, zirconium, hastelloy, lined PTFE or lined Ni (Ni6) according to different requirements of media.

7.Opening port of conventional kettle lid:

Gas port with needle valve, liquid port with needle valve and tube inserting the bottom, the charging port for the solid with pipe plug, measuring and controlling temperature port with platinum resistance, security blasting port of pressure gauge with pressure gauge safety explosion-proof device, and inlet and outlet of cooling coil inside the reactor with tap.

8.Controller Device

Equipped with automatic temperature regulator, temperature control accuracy of ± 1 °C; With speed display and stepless speed regulation function;

The heating power can be adjusted to achieve the purpose of automatic thermostat.

9.Other Accessories

If the user have other special requirements on kettle cover, kettle body opening, the internal structure, high and low pressure, stirring paddle, and other the supporting device (such as condensate return unit, constant feeding tank, receiver, condenser, etc.) ,we can manufacture reactors according to users’ requirements.

Performance index of High Pressure Laboratory Reactor

The stirring reactor laboratory miniature high-pressure reaction kettle
Model	THR50	THR100	THR250	THR500
Material capacity(L)	50ml	100ml	250ml	500ml
The working interface	Touch control liquid crystal display	Touch control liquid crystal display	Touch control liquid crystal display	Touch control liquid crystal display
The maximum operating temperature	250℃	250℃	250℃	250℃
The maximum operating temperature with PTFE Liner	180℃	180℃	180℃	180℃
Heating mode	Module heating	Module heating	Module heating	Module heating
The heating power	1.2KW	1.2KW	1.5KW	2.0KW
Stirring speed	0-1200rpm	0-1200rpm	0-1300rpm	0-1300rpm
Stirring method	The internal magnetic stirring	The internal magnetic stirring	The internal magnetic stirring	The internal magnetic stirring
The stirring power	40W	40W	40W	80W
The maximum working pressure	10Mpa	10Mpa	10Mpa	10Mpa
Materials of construction	SS316L (standard); (Alloy TA2, ALLOY C-276, Nickel ALlloy, Zirconium materials are optional)
PTFE liner	Optional
Note: 1. Max volume 2000ml could be customized. 2.Suitable for the material which temp <250℃ and is nonmagnetic. 3.Temperature timing set, temp. set when working, this function is optional.
