Unique good price slice ice machine plant
- 3000 Set / Sets per Month
- Zhejiang / Shanghai / Tianjin Port
- Credit Card
- 200kg Dry ice pellets making machine for dry ice production
- New York Liquid Flowmeter 024W26116-002 Flow Switch HF68 Mechanical Target
- New slide valve potentiometer coupling 111Q0451313
- New Kunteng 5 motherboard 649C1152G01 York FRICK circuit board 649C1158G01
- New York FRICK Industrial Refrigeration Unit 649C1091G01 Kunteng 4-LX Control System Main Board
- New GEA explosion-proof energy level sensor model 62750016
Product Details
Condition: | New | Capacity: | 3tons/24h | Place of Origin: | Shaanxi, China |
Brand Name: | TOPTION | Model Number: | TPPB3.0Z-DF/F | Ice Shape: | Flake Ice |
Voltage: | 380V | Power(W): | 9.82kW | Dimension(L*W*H): | 1650*1460*2186mm |
Weight: | 470kg | Certification: | CE | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Unique good price slice ice machine plant
Application Field:
1. Supermarkets, hotels, bars, etc
2. Slaughtering industry
3. Fishery cooling and packing
4. Food processing
5. Fresh preservation for fruit, vegetable, etc
6. Pharmaceutical application
Commercial Flake Ice Machine Features:
1. Reasonable Design
TOPTION ice machine is with integrated structure design for saving installation space, and commercial flake ice machine equips with corrosion-resistant ice storage bin.
2. Stability
TOPTION always aims at researching and manufacturing high efficient and energy-saving refrigeration system; the flake ice machine adopted international ice machine processing technology and experience, and it can produce quality flake ice and constantly operate over 20,000 hours without failure.
3. Sanitation
TOPTION flake ice machine is made of stainless steel, pure aluminium alloy or PE material; flake ice is made inside evaporator so it is not exposed to ambient conditions and it drops into ice bin without mechanical handling, its hygiene level reaches international standards of HACCP and FDA.
4. Water & Energy Saving
TOPTION flake ice machine recycles all unfrozen water back to the ice machine so as to ensure all water is converted to ice and save water resources; Our unique evaporator processing technology makes it better heat exchange efficiency and saves more energy, moreover our patented internally-scraping ice scraper can help reduce energy consumption.
Commercial Flake Ice Machine Technical Specifications | |||||
Model | Capacity (tons/24h) | Refrigeration Capacity (kw) | Total Power | Weight | Dimension (L*W*H)(mm) |
TPPB0.5Z-DF/F | 0.5 | 3.05 | 2.27 KW | 160 kg | 1310*1050*1882 |
TPPB1.0Z-DF/F | 1 | 6.25 | 4.21 KW | 210 kg | 1310*1050*2055 |
TPPB1.5Z-DF/F | 1.5 | 8.15 | 5.42 KW | 330 kg | 1650*1460*2044 |
TPPB2.0Z-DF/F | 2 | 10.32 | 6.72 KW | 360 kg | 1650*1460*2076 |
TPPB2.5Z-DF/F | 2.5 | 13.12 | 8.52 KW | 390 kg | 1650*1460*2095 |
TPPB3.0Z-DF/F | 3 | 19.17 | 9.82 kW | 470 kg | 1650*1460*2186 |
slice ice machine plant pictures
slice ice machine plant producing process
slice ice machine plant packing
Service
Our team
slice ice machine plant
