Unique Innovative Slice Ice Maker Machine Factory

Unique Innovative Slice Ice Maker Machine Factory photo-1
US$ 1 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Capacity:
60tons/24h
Place of Origin:
Shaanxi, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhejiang / Shanghai / Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Capacity 60tons/24h
Place of Origin Shaanxi, China
Brand Name TOPTION
Model Number TPPB60Z-DS/F
Ice Shape Flake Ice
Voltage 380V
Power(W) 189.35kW
Dimension(L*W*H) 5500*3010*3358mm
Weight 12000kg
Certification CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Unique innovative slice ice maker machine factory



Application Field:

1. Aquatic product processing

2. Medium and large chain supermarket

3. Fresh preservation and cooling field application

4. Concrete cooling project

5. Medical facilities

6. Dye chemical industry

7. Mine temperature reduction



Industrial Flake Ice Machine Features:

·Reasonable Design

TOPTION ice machine is with integrated structure design, and all our equipments are designed on the basis of modules, so the spot maintenance is simple by removing the old parts and install the new ones. Furthermore we always give consideration to how to conveniently move the ice machine to other places.

·High Stability

TOPTION always aims at researching and manufacturing high efficient and energy-saving refrigeration system; the flake ice machine adopted international ice machine processing technology and experience, it can produce quality flake ice and constantly operate over 20,000 hours without failure.

·Sanitation

TOPTION flake ice machine is made of stainless steel, pure aluminium alloy or PE material; flake ice is made inside evaporator so it is not exposed to ambient conditions, its hygiene level reaches international standards of HACCP and FDA.

·Water & Energy Saving

TOPTION flake ice machine recycles all unfrozen water back to the ice machine so as to ensure all water is converted to ice and save water resources; Our unique evaporator processing technology makes it better heat exchange efficiency and saves more energy, moreover our patented internally-scraping ice scraper can help reduce energy consumption.





Industrial Flake Ice Machine Technical Specifications

Model

Capacity (tons/24h)

Refrigeration Capacity (kW)

Total Power

Weight

Dimension (L*W*H)(mm)

TPPB3.0Z-DS/F

3

19.17

9.82 kW

470 kg

1615*1015*1120

TPPB5.0Z-DS/F

5

28.8

15.28 kW

1100 kg

1850*1370*1373

TPPB8.0Z-DS/F

8

43.2

22.79 kW

1300 kg

2300*1650*1525

TPPB10Z-DS/F

10

51.5

29.17 kW

1500 kg

2300*1650*1745

TPPB15Z-DS/F

15

106.6

55.47 kW

3200 kg

3200*2010*2061

TPPB20Z-DS/F

20

113.6

65.57 kW

4200 kg

3400*2180*2370

TPPB25Z-DS/F

25

154.8

77.25 kW

5000 kg

3800*2540*2452

TPPB30Z-DS/F

30

184.5

92.40 kW

6000 kg

4500*2540*2772

TPPB35Z-DS/F

35

219.5

108.35 kW

6500 kg

4780*3010*2658

TPPB40Z-DS/F

40

253.8

121.85 kW

7500 kg

5000*3010*2818

TPPB50Z-DS/F

50

329.1

160.15 kW

10000 kg

5000*3010*3158

TPPB60Z-DS/F

60

393.7

189.35 kW

12000 kg

5500*3010*3358







slice ice maker machine factory pictures

Unique innovative slice ice maker machine factory

Unique innovative slice ice maker machine factory

Unique innovative slice ice maker machine factory

Unique innovative slice ice maker machine factory



slice ice maker machine factory producing process

Unique innovative slice ice maker machine factory



slice ice maker machine factory packing

Unique innovative slice ice maker machine factory



Service

Unique innovative slice ice maker machine factory



Our team

Unique innovative slice ice maker machine factory



slice ice maker machine factory
