Creative Low Temp Circulator

Creative Low Temp Circulator thumbnail-1
Creative Low Temp Circulator photo-1
US$ 1 - 1,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other, low temp circulator
Place of Origin:
Shaanxi, China
Brand Name:
TOPTION
Contact Supplier Request Quote Chat Now
Xian Toption Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Tianjin/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, low temp circulator
Place of Origin Shaanxi, China
Brand Name TOPTION
Model Number HX-08
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Product Description of low temperature circulator

HX series of thermostatic circulators provide temperature -40 ℃ ~ 105 ℃ high temperature range, low-temperature liquid, to meet with high and low temperature devices . Especially suitable for chemical reactors, fermenting tanks, rotary evaporators, electron microscopy, Abbey off the first device, evaporator, bio-pharmaceutical reactors supporting the use of experimental equipment. Advanced inner loop and outer loop pump systems, temperature uniformity within the cycle of the instrument constant, external circulating pump output of 16 l / min to 18 L / min in the flow of low and high temperature liquids. 8 liters to 40 liters of working volume within the tank can be placed with biological and chemical reagents or sample containers measured directly the high-temperature test or tests, to achieve a multifunctional.



Key Features of low temperature circulator

1. Air-cooled efficient Hermetic Compressor, cooling speed.

2. Microcomputer intelligent control, temperature accurate temperature.

3. Digital display resolution 0.1 ℃ or 0.01 ℃, with a temperature measurement error correction.

4. Temperature, over-temperature protection, automatic cut off power and alarm.

5. Cooling system over heated, over-current automatic protection.



Technical parameters:

Model

Temperature range(℃)

Digital resolution
  (℃)

Temperature Fluctuation

(℃)

Work Tank size(L)

Circulation Pump flow(L/min)

HX-08

0~105

0.01

±0.05

8

16

HX-010

10

18

HX-015

15

16

HX-020

20

16

HX-030

30

16

HX-0508

-5~105

0.01

±0.05

8

16

HX-0510

10

18

HX-0515

15

16

HX-0520

20

16

HX-0530

30

16

HX-1008

-10~105

0.01

±0.05

8

16

HX-1010

10

18

HX-1015

15

16

HX-1020

20

16

HX-1030

30

16

HX-1508

-15~105

0.01

±0.05

8

16

HX-2008

-20~105

0.01

±0.05

8

16

HX-2010

10

18

HX-2015

15

16

HX-2020

20

16

HX-2030

30

16

HX-3008

-30~105

0.01

±0.1

8

16

HX-3010

10

18

HX-3015

15

16

HX-4008

-40~105

0.1

±0.1

8

16

HX-4015

15

16





 creative low temp circulator
