Home > Manufacturing & Processing Machinery > Chemical Equipment & Machinery > Chemical Drying Equipment > Quality Top Grade Low Dew Point Refrigerated Air Dryer
US$ 100 - 4,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Freeze Drying Equipment
Place of Origin:
Shaanxi, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhejiang / Shanghai /Tianjin port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hotsell Fashionable Air Drier for Compressed AirUS$ 100 - 4,000MOQ: 1 Set -
RD-20A Air Cooling Refrigerated Compressed Air DryerUS$ 100 - 3,000MOQ: 1 Set
-
Unique Super Quality Desiccant Compressed Air DryerUS$ 100 - 4,000MOQ: 1 Set
-
Hotsell Fashionable Adsorption Air DryerUS$ 100 - 4,000MOQ: 1 Set
-
RD-10A Air Cooling Refrigerated Compressed Air DryerUS$ 100 - 3,000MOQ: 1 Set
Condition
New
Type
Freeze Drying Equipment
Place of Origin
Shaanxi, China
Brand Name
TOPTION
Model Number
RD-230A
Voltage
220V
Power(W)
2.5HP
Dimension(L*W*H)
1500*600*1100mm
Weight
450KG
Certification
ISO9001
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Quality top grade low dew point refrigerated air dryer
| Specification: | ||||||
| Name | Quality top grade low dew point refrigerated air dryer | |||||
| Model | Capacity | Power of compressor (HP) | Pipe Diameter | Power | Size (mm) | Weight |
| NM3/min | (KG) | |||||
| RD-5A | 0.7 | 1/4 | 1/2″ | 220V 50HZ | 700*400*740 | 100 |
| RD-10A | 1.5 | 1/2 | 3/4″ | 700*400*740 | 120 | |
| RD-20A | 2.6 | 3/4 | 1″ | 750*500*750 | 150 | |
| RD-30A | 3.8 | 1 | 2001-1-2 | 750*500*750 | 180 | |
| RD-60A | 6.5 | 1.5 | 2001-1-2 | 800*550*800 | 200 | |
| RD-80A | 8.5 | 2 | 2001-1-2 | 1200*500*1000 | 250 | |
| RD-110A | 11 | 2.5 | 2″ | 3Φ380V 50HZ | 1200*600*1000 | 350 |
| RD-130A | 13.5 | 3.5 | 2″ | 1200*600*1000 | 380 | |
| RD-180A | 18 | 4 | DN65 | 3Φ | 1500*600*1100 | 400 |
| RD-230A | 23 | 5 | DN80 | 380V 50HZ | 1500*600*1100 | 450 |
| RD-280A | 28 | 6 | DN80 | 1780*750*1300 | 600 | |
| RD-350A | 35 | 7.5 | DN80 | 1780*750*1300 | 700 | |
| RD-450A | 45 | 10 | DN100 | 1850*800*1350 | 950 | |
| RD-550A | 55 | 12 | DN100 | 1850*800*1350 | 1200 | |
| RD-650A | 65 | 15 | DN125 | 2000*900*1400 | 1500 | |
| Basic specifications | ||||||
| Air Inlet temperature | ≤45°C | |||||
| Temp dew point | 0°C--8°C | |||||
| Environment temp | 2°C--38°C | |||||
| Refrigerant | R22 | |||||
| Air inlet pressure | 0.2-1.0Mpa (high pressure can be customized) | |||||
| Service | Customized,specifications or stainless steel condensation purifier | |||||
| Main features | 1. The compressor is imported from US TECUMSEH, BRISTOL, France MANEURCP, etc, with stable performance, low noise, power saving, and long using life advantages | |||||
| 2. Pre-cooler with inside and outside multi-finned exchanger tubes,Efficiency three times more than before, can help to save 60% power consumption | ||||||
| 3. Super evaporator design, suitable for all kinds of climate, ensures the stable dew point for you | ||||||
| 4. Air-water separator adopts double dissociation design, can separate and discharge the water totally | ||||||
| 5. Micro computer system is optional, this system with inlet and outlet temp display, dew point temp display, pressure display, mistake alarm functions. It can also help to realize the computer centralized controlling | ||||||
low dew point refrigerated air dryer pictures
low dew point refrigerated air dryer producing process
low dew point refrigerated air dryer packing
Service
Our team
low dew point refrigerated air dryer
