Lab Rotary Evaporator (3L, Water Bath, Electric Lifting, RE-3000A)

Lab Rotary Evaporator (3L, Water Bath, Electric Lifting, RE-3000A) thumbnail-1
Lab Rotary Evaporator (3L, Water Bath, Electric Lifting, RE-3000A) photo-1
US$ 1 - 2,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Distillation
Power Source:
Electric
Contact Supplier Request Quote Chat Now
Xian Toption Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhejiang / Shanghai / Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Distillation
Power Source Electric
Process Rotary
Place of Origin Shaanxi, China
Brand Name TOPTION
Model Number RE-3000A
Voltage 220V, 220V 50/60Hz
Power(W) 1500W
Dimension(L*W*H) 600*760*680
Weight 30Kg
Certification ISO9001-2008
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Lab Rotary Evaporator RE-3000A
1. Water bath/Oil bath for you
2. Used in medical,pharmacy, chemical,cosmetic industry, etc

                                                          Lab Rotary Evaporator  RE-3000A

                                 (3L, water bath, electric lifting, can match with vacuum pump )


    Rotary Evaporator is the use of vacuum pressure, constant temperature heating conditions, using the rotating bottle constant speed rotation, the formation of large area thin film, high evaporation equipment installations.

Rotary evaporator is mainly used for pharmaceutical, chemical and bio-pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high-temperature decomposition of the variability of biological products Purifying





Key Features of  RE-3000A Lab Rotary Evaporator
Rocker plate button: toggle main board under the Ministry of pressure rise, toggle press the host fall under the subordinates. With ring nuts: smooth rotation automatically fasten rotating bottle, reverse rotation axis of rotation speed shifting. Stepless speed regulation.

  Lab Rotary Evaporator (3L, water bath, electric lifting, RE-3000A)Lab Rotary Evaporator (3L, water bath, electric lifting, RE-3000A)

Technical parameters of  RE-3000A Lab Rotary Evaporator

Type

RE-3000A

Host

plate buttons, fast automatic lift 0-150mm

Speed

Speed digital 20-200r/min

The heating pot

Teflon composite pan ,fullyenclosed heater,power 1.4KW

Temperature range

Automatic temperature control, temperature digital display, RT-90

condenser

vertical, high-temperature high-quality glass I double back a ball off of Condenser, large diameter airway, improve the efficiency of evaporation

power

1.5kw

voltage

220V 50Hz



























      Our factory is professional in 50ml, 1L, 2L, 3L, 5L, 10L, 20L, 50L Rotary Evaporator. Water bath or oil bath can be produced according to customers’ requests!


       Customized Glass Reactor also welcome here !!!



      TOPTION---Your top option !
