RE-5L With Water Bath Rotary Evapoator

RE-5L With Water Bath Rotary Evapoator thumbnail-1
RE-5L With Water Bath Rotary Evapoator photo-1
US$ 600 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Pharmaceutical Processing
Power Source:
Electric
Contact Supplier Request Quote Chat Now
Xian Toption Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhejiang / Shanghai / Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Pharmaceutical Processing
Power Source Electric
Process Vacuum Distillation
Place of Origin Shaanxi, China
Brand Name TOPTION
Model Number RE-5000
Voltage 220V
Power(W) 2100W
Dimension(L*W*H) 120x80x220
Weight 50kG
Certification ISO9001
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

RE-5L with Water Bath Rotary Evapoator
with discharging valve for easy cleaning of collection bottle and continous distillation

                                             RE-5000 (5L) with Water Bath Rotary Evapoator
        Rotary Evaporator is the use of vacuum pressure, constant temperature heating conditions, using the rotating bottle constant speed rotation, the formation of large area thin film, high evaporation equipment installations.

Rotary evaporator is mainly used for pharmaceutical, chemical and bio-pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high-temperature decomposition of the variability of biological products was concentrated and purified. /enotherproduct.asp?username=tion

RE-5L with Water Bath Rotary Evapoator
RE-5L with Water Bath Rotary EvapoatorRE-5L with Water Bath Rotary EvapoatorRE-5L with Water Bath Rotary Evapoator

Key Features of RE-5000 (5L) with Water Bath Rotary Evapoator

New floor rotary evaporator, using a large capacity, large diameter rotary evaporation flask, increased evaporation area, in the decompression in the water bath, side spin, side heating, diffusion or evaporation of the solution, a wide range of applications and sample size concentration, drying, extraction, recycling, chemical, pharmaceutical, food, environmental, university research laboratory and industrial mass production of such good equipment.

the technical parameters of RE-5000 (5L) with Water Bath Rotary Evapoator





type

RE-5000

Down mode

Rocker plate buttons,electric lift

The speed range (rpm)

0~110

Temperature range(°C)

(water) RT~98

condenser

Vertical type, double serpentine tube

Rotating bottle max capacity(L)

5

Max capacity to collect bottles(L)

3

Motor power(W)

2120

Size

600*400*850 mm





        1L, 2L, 3L, 5L, 10L, 20L, 50L Rotary Evaporator can be provided by us. You can choose the rotary evaporator with water bath or oil bath.

       Rotary Evaporator with Discharging Valve, easy for collecting material and clean !!!

       We believe the quality will not let you down !
