Help CenterHigh Frequency Solar Power Inverter
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Kemapo
Model Number:
High frequency solar power inverter JD800-3000
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JD75DA 150DA 150Y 200Y AC Power InverterNegotiableMOQ: 1 Piece -
High Frequency DC-AC Power Inverter JD300N-600NNegotiableMOQ: 1 Piece
-
HI 4000W-6000W Modified Sine Wave Power InverterUS$ 250 - 250MOQ: 15 Pieces
-
High Frequency DC-AC Power Inverter JD75DA 150DA 150Y 200YNegotiableMOQ: 1 Piece
-
Single Phase Power Inverter JD75U-200UNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Kemapo
Model Number
High frequency solar power inverter JD800-3000
Output Power
1 - 200KW
Output Type
Single
Size
475*290*570
Input Voltage
10.5V to 15.5V±0.3
Output Voltage
110V ±10 V
Type
DC/AC Inverters
Output Frequency
50/60±5 HZ
Solar power inverter
Key Features
1.High frequency solar power inverter
2.Single phase modefied sine wave ouput
3.Full range protection for the inverter and the battery.
4.With USB port
5.Smaller and light
Technical Specifications
| Mode | JD 800 | JD 1000 | JD 1500 | JD2000 | JD2500 | JD3000 |
| Continuous power (W) | 800 | 1000 | 1500 | 2000 | 2500 | 3000 |
| Surge capability (W) | 1600 | 2000 | 3000 | 4000 | 5000 | 6000 |
| DC input (VDC) | 12/24 | 12/24 | 12/24 | 12/24 | 12/24 | 12/24 |
| DC input range | 10.5V to 15.5V±0.3 or 21V to 31V±0.3 | |||||
| AC output | 220V,110V ±10 V | |||||
| Output frequency | 50/60±5 HZ | |||||
| Output waveform | Modified sine wave | |||||
| Efficiency | >85% | |||||
| Battery low alarm | 10.2-10.8V or 20.4-21.6V | |||||
| Over discharge protection | 10 ±0.5V or 20±0.5V shut off | |||||
| Resume voltage | 11.7V--12.8V or 23.4-25.6V auto restart | |||||
| Over voltage protection | 15V-16.5V, 30-33V shut off. | |||||
| Overload protection | Shut off while over 120% rated capacity | |||||
| With cooling fan | Yes | |||||
| USB | Yes | Optional | Yes | Yes | Yes | |
| DC conection | With cable | |||||
| Connection convertor | No | No | No | No | No | No |
| Product package | Paper skin | |||||
| Running temperature | 20 to 40 degree | |||||
| High temperature protection | Yes | |||||
| Short circuit protection | Yes | |||||
| Reverse polarity protection | Yes | |||||
| Product size(mm) | 200*146*60 | 220*146*60 | 250*146*60 | 385*200*90 | 385*200*90 | 385*200*90 |
| Carton size (mm) | 565*305*365 | 560*305*365 | 455*335*350 | 480*445*245 | 485*445*245 | 485*445*245 |
| Carton weight (kg) | 21.5 | 22 | 20.5 | 20 | 20.5 | 20.5 |
| PCS /CTN | 10 | 10 | 8 | 3 | 3 | 3 |
