20L 50L Rotary Evaporator With Water Bath

Specifications

20L 50L rotary evaporator with water bath
1.Rotary Evaporator made in China
2.Rotary Evaporator 10, 20, 50L capacity

                 20L  50L rotary evaporator with water bath



Introduction of 20L  50L rotary evaporator with water bath



1. The revolving evaporator is especially suitable for heat sensitive material to concentrate, crystal, separation, solvent recovery and so on.



2. It is one of the necessary basic instrument of the chemical industry, pharmaceutical industry, universities and research laboratories and other industries.



Features of 20L  50L rotary evaporator with water bath:

1. High Evaporation, high recovery, conversion and use of advanced electronic speed control to ensure stable operation of t motor, Chinese rotary evapoator with 10L, 20L, 50L capacity.

2. Bath life the pot, reduce breakage, evaporation of low boiling point, the collection bottles can be immersed in an ice bath to reduce the secondary evaporation.

3. Collection bottle milling port connection, can be easily removable, sealing the fine

4. High temperature long –lasting sealing, dynamic sealing system to ensure high temperature corrosion resistance and long life, particularly good air tightness.

5. Japanese technology AC induction motor, variable speed, no brush, no spark, can work effectively for a long time.

6. Chassis, bath pot, main bar, and stainless steel shaft made of high quality, attractive appearance corrosion

7. Intelligent temperature control, water and oil bath, dual-use, more widely used. Temperature fluctuation is only ±0.2°C. Evaporation is more stable, not easily washed material.

8. Whole series modular design, scalability, easy installation, easy maintenance.

9. According to user needs, electrical part can adopt explosion-proof configuration (Optional).



Specification of 20L  50L rotary evaporator with water bath

Model	RE-2	RE-5	RE-10	RE -20	RE-50
Roation bottle (L)	0.5L/1 29#	5L/50#	10L	20L	50L
Collection bottle(L)	1L /35#	3L/40#	5L	10L+3L	20L+5L
Motor power(W)	40	60	90	120	180
vacuum(Mpa)	0.098	0.098	0.098	0.098	0.098
Rotation speed(rpm)	10-180	10-90	5-110	5-110	5-110
Evaporation speed (H2O)(L/h)	1.2	2	3.5	5	7
voltage(V)	220	220	220	220	220/380
size(cm)	55*35*75	55*35*110	100*50*180	110*70*200	120*80*220



Our factory is also professional in Rotary Evaporator with capacity from 50ml ~ 50L, which kind is ok for you?



Do you need Vacuum Pump for providing vacuum condition for your experiment?
