RE-52AA Cheap Small Rotary Evaporator

Description of RE-52AA Cheap Small Rotary Evaporator
Rotary Evaporator is the use of vacuum pressure, constant temperature heating conditions, using the rotating bottle constant speed rotation, the formation of large area thin film, high evaporation equipment installations.

Rotary evaporator is mainly used for pharmaceutical, chemical and bio-pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high-temperature decomposition of the variability of biological products was concentrated and purified.

 Key Features of  RE-52AA Cheap Small Rotary Evaporator

  New floor rotary evaporator, using a large capacity, large diameter rotary evaporation flask, increased evaporation area, in the decompression in the water bath, side spin, side heating, diffusion or evaporation of the solution, a wide range of applications and sample size concentration, drying, extraction, recycling, chemical, pharmaceutical, food, environmental, university research laboratory and industrial mass production of such good equipment.

Model

RE-52A

RE-52AA

Down mode

Manual lifting

Electric lifting

The speed range(rpm)

0-120

0-120

Temperature range(°C)

RT-100 (water bath) / RT-180 (oil bath)

condenser

Vertical type, double serpentine tube

With small capacity cold trap

Rotating bottle maximum capacity(L)

2

2

Maximum capacity to collect bottles(L)

2

2

Motor power (W)

1060

1100
