RE-5203A Rotary Evaporator / Rotary Evaporation Machine

Specifications

3L Rotary Evapoator
1. Cost-effective with high presicion temp controller
2. Widely used
3. can be made with water / oil bath

                                RE-5203A Rotary Evaporator / Rotary Evaporation Machine

      Rotary Evaporator is the use of vacuum pressure, constant temperature heating conditions, using the rotating bottle constant speed rotation, the formation of large area thin film, high evaporation equipment installations.

Rotary evaporator is mainly used for pharmaceutical, chemical and bio-pharmaceutical industry concentration, crystallization, drying, separation and dissolution of coal recovery. The principle is: in a vacuum condition, constant temperature heating, to rotate bottles constant rotation, the material in the sidewall formation of large area thin film, high evaporation. Solubilization by high glass condenser vapor cooling, recovery in the collection bottle, greatly improve the efficiency of evaporation, particularly easy to use in high-temperature decomposition of the variability of biological products was concentrated and purified.


Key Features of RE-5203A Rotary Evaporator / Rotary Evaporation Machine

New floor rotary evaporator, using a large capacity, large diameter rotary evaporation flask, increased evaporation area, in the decompression in the water bath, side spin, side heating, diffusion or evaporation of the solution, a wide range of applications and sample size concentration, drying, extraction, recycling, chemical, pharmaceutical, food, environmental, university research laboratory and industrial mass production of such good equipment.

Technical parameters of RE-5203A Rotary Evaporator / Rotary Evaporation Machine



type	RE-5203A
Down mode	Rocker plate buttons, electric lift
The speed range(rpm)	0~150
Temperature range(°C)	RT~100
condenser	Vertical type, double serpentine tube
Rotating bottle maximum capacity (L)	3
Maximum capacity to collect bottles (L)	2
Motor power (W)	1630



        1L, 2L, 3L, 5L, 10L, 20L, 50L Rotary Evaporator can be provided by us. You can choose the rotary evaporator with water bath or oil bath.

       We believe the quality will not let you down !
